3-1462039-2

24V 2A@250VAC 2 Form C: 2C (DPDT-CO) Through Hole Signal Relays, Up to 2 Amps

Through HoleRoHSActive

Signal Relays Slim line, low profile and min.board-space, Switching current, power and voltage, Low coil power consumption, High dielectric and surge capability, High mechanical shock resistance

Manufacturer: TE Connectivity
Manufacturer part #: 3-1462039-2
Store part #: C1560594
Package / case: Through Hole
Category: Signal Relays, Up to 2 Amps
Packaging: Tube-packed

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

100 in stock

#C1560594

Stock & price checked 10 days ago

Quantity	Unit price	Pack price
1+	₹1,026.83	₹1,026.83
10+	₹874.23	₹8,742.30
30+	₹781.31	₹23,439.30
100+	₹703.37	₹70,337.00

Quantity (min 1)

1 × ₹1,026.83

₹1,026.83

excl. GST

₹1,211.66 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 1,000 per tube

3-1462039-2

₹1,026.83 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Coil Resistance: 2.88kΩ
Coil Voltage: 24V
Release Time: 1ms
Operate Time: 1ms
Number of Pins: 8
Operating Temperature: -40℃~+85℃
Width: 6mm
Contact Resistance: 50mΩ
Length: 10mm
Contact Rating: 2A@250VAC
Switching Voltage(Max): 220V@DC;250V@AC
Contact Form: 2 Form C: 2C (DPDT-CO)
Coil Rated Power: 200mW

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
ECCN: EAR99
Packaging: Tube-packed
Standard pack: 1,000 / Tube
Sold per: Piece
Minimum order: 1
Unit weight: 1.091 g

Overview

Slim line 10x6mm, low profile 5.65mm and min. board- space 60mm². Switching current 2/5A, switching power 60W/62.5VA and switching voltage 220VDC/250VAC. Low coil power consumption, 140mW standard, 100mW for high sensitive version, 50mW for ultra high sensitive version and 100mW for bistable version. High dielectric and surge capability up to 2500Vrms between open contacts and 2500Vrms between coil and contacts. High mechanical shock resistance up to 50g functional.

Applications

Telecommunication
access and transmission equipment
optical network terminals
modems
office and business equipment
consumer electronics
measurement and test equipment
industrial control
medical equipment
HVAC

Key features

Slim line 10x6mm, low profile 5.65mm and min. board-space 60mm²
Switching current 2/5A, switching power 60W/62.5VA and switching voltage 220VDC/250VAC
Low coil power consumption, 140mW standard, 100mW for high sensitive version, 50mW for ultra high sensitive version and 100mW for bistable version
High dielectric and surge capability up to 2500Vrms between open contacts and 2500Vrms between coil and contacts
High mechanical shock resistance up to 50g functional
