YAGEODatasheet (PDF)
AC1210JR-075M6L
500mW 5.6MΩ 200V Thick Film Resistor ±100ppm/℃ ±5% 1210 Chip Resistor - Surface Mount RoHS
1210ROHS3 CompliantActive
RES 5.6MΩ ±5% 500mW 1210
- Manufacturer
- YAGEO
- Manufacturer part #
- AC1210JR-075M6L
- Store part #
- C728087
- Package / case
- 1210
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,950 in stock
#C728087
Stock & price checked 47 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 50+ | ₹2.12 | ₹106.00 |
| 500+ | ₹1.69 | ₹845.00 |
| 1,500+ | ₹1.46 | ₹2,190.00 |
| 5,000+ | ₹1.32 | ₹6,600.00 |
| 25,000+ | ₹1.20 | ₹30,000.00 |
| 50,000+ | ₹1.14 | ₹57,000.00 |
50 × ₹2.12
₹106.00
excl. GST
₹125.08 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
AC1210JR-075M6L
₹106.00 for 50 + GST
Specifications
- Power(Watts)
- 500mW
- Resistance
- 5.6MΩ
- Voltage Rating
- 200V
- Type
- Thick Film Resistor
- Temperature Coefficient
- ±100ppm/℃
- Tolerance
- ±5%
- Operating Temperature
- -55℃~+155℃
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 50 (multiples of 50)
- Unit weight
- 0.034 g
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | 1210W2J0565T5E#C784315UNI-ROYAL · 1210 | UNI-ROYAL | 1210 | 4,750 | ₹0.9658 · 4,750 in stock | View |
 | CR1210F5M60P05Z#C147162EVER OHMS · 1210 | EVER OHMS | 1210 | 200 | ₹1.68 · 200 in stock | View |
 | 1210W2F5604T5E#C422271UNI-ROYAL · 1210 | UNI-ROYAL | 1210 | 4,087 | ₹1.72 · 4,087 in stock | View |
| AF1210JR-075M6L#C2116374YAGEO · 1210 | YAGEO | 1210 | On request | Price on request | Quote | |
| AS0707J0565T5E#C2770273UNI-ROYAL · 1210 | UNI-ROYAL | 1210 | On request | ₹8.45 · 0 in stock | View | |
