AM1DS-0503DJZ
Isolated Module DC DC Converter Buck 2 Output ±3.3V ±152mA 4.5V~5.5V Input
Fixed-voltage input isolated non-regulated dual-output DC/DC modular power supply
- Manufacturer
- YLPTEC
- Manufacturer part #
- AM1DS-0503DJZ
- Store part #
- C22372329
- Package / case
- SIP,19.5x6mm
- Category
- DC DC Converters
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
25 in stock
#C22372329
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹390.91 | ₹390.91 |
| 10+ | ₹330.84 | ₹3,308.40 |
| 25+ | ₹293.24 | ₹7,331.00 |
| 100+ | ₹254.58 | ₹25,458.00 |
| 500+ | ₹237.16 | ₹1,18,580.00 |
| 1,000+ | ₹229.81 | ₹2,29,810.00 |
1 × ₹390.91
₹390.91
excl. GST
₹461.27 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 25 per tube
AM1DS-0503DJZ
₹390.91 for 1 + GST
Specifications
- Output Voltage
- ±3.3V
- Ripple Noise
- 30mVp-p
- Type
- Plastic encapsulated type
- Operating Temperature
- -40℃~+85℃
- Voltage - Supply
- 4.5V~5.5V
- Capacitive Load(Max)
- 1200uF
- Number of Outputs
- 2
- Iout
- 152mA
- Height
- 10mm
- Frequency - Switching
- 100kHz
- Isolation Voltage(Vrms)
- 1.5kV
- Output Power
- 1W
- Features
- Short Circuit Protection;Automatic fault recovery;Over-temperature protection
- Conversion Efficiency
- 80%
- Length
- 19.5mm
- Width
- 6mm
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tube-packed
- Standard pack
- 25 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 4.2 g
Overview
1W, fixed voltage input, isolated unregulated dual positive/negative output, DC/DC module power supply. This series is specifically designed for applications in on-board power systems that require generating a set of voltages isolated from the input power supply.
Applications
- Pure digital circuit applications
- General low-frequency analog circuit applications
- Relay driver circuits
- Data switching circuit applications
Key features
- Fixed voltage input, isolated unregulated dual output, 1W power
- Low no-load power consumption: 0.025W (Typ.)
- Isolation voltage: 1500VDC
- Efficiency: up to 90%
- Operating temperature range: -40°C~+85°C
- MTBF 23.5 million hours (3500000Hrs)
- Output short-circuit protection: continuous short-circuit protection, auto-recovery
- Compact SIP package, plastic housing
- International standard pinout
- Ripple/Noise (20MHz bandwidth): 30mVp-p (Typ.)
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | A0503S-1WR3#C5369383YLPTEC · SIP,19.5x6mm | YLPTEC | SIP,19.5x6mm | 22 | ₹218.47 · 22 in stock | View |
 | E0503S-1WR3#C5369549YLPTEC · SIP,19.5x6mm | YLPTEC | SIP,19.5x6mm | 76 | ₹232.83 · 76 in stock | View |
