B0505S-1WR3Isolated Module DC DC Converter 5V 200mA 4.5V~5.5V Input
From
₹101.28
1,38,171 in stock
YLPTECDatasheet (PDF)
AM2DM-0509DH60-NZ
Isolated Module DC DC Converter Boost 2 Output ±9V ±112mA 4.5V~5.5V Input
SIP,19.5x9.8mmRoHSActive
DC/DC modular power supply, 2W fixed-voltage input, isolated non-regulated dual positive and negative outputs
- Manufacturer
- YLPTEC
- Manufacturer part #
- AM2DM-0509DH60-NZ
- Store part #
- C22372241
- Package / case
- SIP,19.5x9.8mm
- Category
- DC DC Converters
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
17 in stock
#C22372241
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹698.42 | ₹698.42 |
| 10+ | ₹596.98 | ₹5,969.80 |
| 25+ | ₹536.90 | ₹13,422.50 |
| 100+ | ₹475.99 | ₹47,599.00 |
| 500+ | ₹447.84 | ₹2,23,920.00 |
| 1,000+ | ₹435.23 | ₹4,35,230.00 |
1 × ₹698.42
₹698.42
excl. GST
₹824.14 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 25 per tube
AM2DM-0509DH60-NZ
₹698.42 for 1 + GST
Specifications
- Output Voltage
- ±9V
- Ripple Noise
- 80mVp-p
- Operating Temperature
- -40℃~+85℃
- Quiescent Supply Current
- 5mA
- Voltage - Supply
- 4.5V~5.5V
- Capacitive Load(Max)
- 560uF
- Number of Outputs
- 2
- Iout
- 112mA
- Height
- 12.5mm
- Frequency - Switching
- 100kHz
- Isolation Voltage(Vrms)
- 6kV
- Conversion Efficiency
- 89%
- Features
- Short Circuit Protection;Automatic fault recovery;Over-temperature protection
- Output Power
- 2W
- Length
- 19.5mm
- Width
- 9.8mm
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tube-packed
- Standard pack
- 25 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 4 g
Overview
2W, fixed voltage input, isolated unregulated dual positive/negative output, DC/DC module power supply. This series is specifically designed for applications in on-board power systems that require generating a set of voltages isolated from the input power supply.
Applications
- Pure digital circuit applications
- General low-frequency analog circuit applications
- Relay driver circuits
- Data switching circuit applications
Key features
- Regulated voltage input, isolated unregulated output, 2W power
- Isolation voltage: 6000VDC
- Low no-load power consumption: 0.025W (Typ.)
- Efficiency: up to 90%
- Operating temperature: -40°C~+85°C
- MTBF 23.5 million hours (3500000Hrs)
- Output short circuit protection: continuous short circuit protection, auto recovery
- Compact SIP package, plastic housing
- International standard pinout
- Ripple/Noise (20MHz bandwidth): 30mVp-p (Typ.)
Alternatives
Similar parts — check the datasheet before substituting.
