MICROCHIPDatasheet (PDF)
APT60D40BG
37ns 400V 1.5V@60A 60A TO-247 Single Diodes RoHS
TO-247ROHS3 CompliantActive
- Manufacturer
- MICROCHIP
- Manufacturer part #
- APT60D40BG
- Store part #
- C17499126
- Package / case
- TO-247
- Category
- Single Diodes
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
10 in stock
#C17499126
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹1,304.36 | ₹1,304.36 |
| 10+ | ₹1,160.61 | ₹11,606.10 |
| 30+ | ₹1,073.02 | ₹32,190.60 |
| 90+ | ₹999.53 | ₹89,957.70 |
1 × ₹1,304.36
₹1,304.36
excl. GST
₹1,539.14 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 30 per tube
APT60D40BG
₹1,304.36 for 1 + GST
Specifications
- Reverse Recovery Time (trr)
- 37ns
- Operating Junction Temperature Range
- -55℃~+175℃
- Voltage - DC Reverse (Vr) (Max)
- 400V
- Voltage - Forward(Vf@If)
- 1.5V@60A
- Reverse Leakage Current (Ir)
- 250uA@400V
- Current - Rectified
- 60A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 30 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 9.11 g
Overview
APT60D40BG is a 400 V, 60 A fast soft-recovery rectifier silicon diode in a TO-247 package.
Applications
- Power Factor Correction (PFC), freewheeling diodes (motor controllers, inverters/converters), snubber diodes, anti-parallel diodes (switch-mode power supplies, inverters)
Key features
- Fast recovery time
- Soft recovery characteristics
- Low forward voltage
- Low leakage current
- RoHS compliant
