ROHMDatasheet (PDF)
BA00BC0WT
1.5V~12V Positive Adjustable TO-220FP-5 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
TO-220FP-5ROHS3 CompliantDiscontinued
- Manufacturer
- ROHM
- Manufacturer part #
- BA00BC0WT
- Store part #
- C5950399
- Package / case
- TO-220FP-5
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
11 in stock
#C5950399
Stock & price checked 39 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹507.00 | ₹507.00 |
| 10+ | ₹495.66 | ₹4,956.60 |
| 30+ | ₹488.17 | ₹14,645.10 |
| 100+ | ₹480.69 | ₹48,069.00 |
1 × ₹507.00
₹507.00
excl. GST
₹598.26 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 500 per tube
BA00BC0WT
₹507.00 for 1 + GST
Specifications
- Output Voltage
- 1.5V~12V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+105℃
- Output Configuration
- Positive
- Operating Voltage
- 16V
- Output Current
- 1A
- Output Type
- Adjustable
- Features
- Enable control;Over Current Protection;Thermal shutdown
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Discontinued
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 500 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 3.827 g
Overview
The BAxxBC0 are low-saturation regulators with an output current of 1.0 A and an output voltage accuracy of ±2%. A broad output voltage range is offered, from 1.5V to 10V, and built-in overcurrent protection and thermal shutdown (TSD) circuits prevent damage due to short-circuiting and overloading, respectively.
Applications
- All electronic devices that use microcontrollers and logic circuits
Key features
- Output voltage accuracy: ±2%
- Broad output range available: 1.5 V - 10 V (BAxxBC0 series)
- Low saturation-voltage type with PNP output
- Built-in overcurrent protection circuit
- Built-in thermal shutdown circuit
- Integrated shutdown switch (BAxxBC0WT, BAxxBC0WT-5, or BAxxBC0WFP Series, BA00BC0WCP-V5)
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| BA00BC0WT-V5#C17693518ROHM · TO-220FP-5 | ROHM | TO-220FP-5 | On request | ₹176.22 · 0 in stock | View | |
