HXY MOSFETDatasheet (PDF)
BAR46AFILM-HXY
4ns 100V 1 Pair Common Anode 1V@10mA 200mA SOT-23 Single Diodes
SOT-23RoHSActive
- Manufacturer
- HXY MOSFET
- Manufacturer part #
- BAR46AFILM-HXY
- Store part #
- C52754621
- Package / case
- SOT-23
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
160 in stock
#C52754621
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹5.57 | ₹55.70 |
| 100+ | ₹4.48 | ₹448.00 |
| 300+ | ₹3.94 | ₹1,182.00 |
| 3,000+ | ₹3.55 | ₹10,650.00 |
| 6,000+ | ₹3.21 | ₹19,260.00 |
| 9,000+ | ₹3.06 | ₹27,540.00 |
10 × ₹5.57
₹55.70
excl. GST
₹65.73 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
BAR46AFILM-HXY
₹55.70 for 10 + GST
Specifications
- Reverse Recovery Time (trr)
- 4ns
- Voltage - DC Reverse (Vr) (Max)
- 100V
- Diode Configuration
- 1 Pair Common Anode
- Pd - Power Dissipation
- 350mW
- Voltage - Forward(Vf@If)
- 1V@10mA
- Reverse Leakage Current (Ir)
- 5uA@75V
- Non-Repetitive Peak Forward Surge Current
- 2A
- Current - Rectified
- 200mA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.027 g
Overview
Key features
- Average rectified output current: I0 = 200 mA
- Power dissipation: 350mW
