HXY MOSFETDatasheet (PDF)
BAT46JFILM-HXY
1 Independent 100V 1V@250mA 150mA SOD-323 Single Diodes
SOD-323RoHSActive
- Manufacturer
- HXY MOSFET
- Manufacturer part #
- BAT46JFILM-HXY
- Store part #
- C52754516
- Package / case
- SOD-323
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
80 in stock
#C52754516
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹4.21 | ₹84.20 |
| 200+ | ₹3.35 | ₹670.00 |
| 600+ | ₹2.86 | ₹1,716.00 |
| 3,000+ | ₹2.57 | ₹7,710.00 |
| 9,000+ | ₹2.32 | ₹20,880.00 |
| 21,000+ | ₹2.18 | ₹45,780.00 |
20 × ₹4.21
₹84.20
excl. GST
₹99.36 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
BAT46JFILM-HXY
₹84.20 for 20 + GST
Specifications
- Diode Configuration
- 1 Independent
- Voltage - DC Reverse (Vr) (Max)
- 100V
- Operating Junction Temperature Range
- -40℃~+125℃
- Voltage - Forward(Vf@If)
- 1V@250mA
- Reverse Leakage Current (Ir)
- 2uA@75V
- Non-Repetitive Peak Forward Surge Current
- 750mA
- Current - Rectified
- 150mA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 0.023 g
Overview
Key features
- High breakdown voltage
- Low forward voltage
- Guard ring structure for transient protection
