BD677
60V 750 4A NPN SOT-32-3 Single Bipolar Transistors RoHS
SOT-32-3ROHS3 CompliantActive
- Manufacturer
- ST
- Manufacturer part #
- BD677
- Store part #
- C262872
- Package / case
- SOT-32-3
- Category
- Single Bipolar Transistors
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
119 in stock
#C262872
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹79.18 | ₹79.18 |
| 10+ | ₹61.35 | ₹613.50 |
| 50+ | ₹53.74 | ₹2,687.00 |
| 100+ | ₹44.39 | ₹4,439.00 |
| 500+ | ₹40.03 | ₹20,015.00 |
| 1,000+ | ₹37.41 | ₹37,410.00 |
1 × ₹79.18
₹79.18
excl. GST
₹93.43 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 50 per tube
BD677
₹79.18 for 1 + GST
Specifications
- Current - Collector Cutoff
- 2mA
- Vbe On(VBE(on))
- 2.5V
- Collector - Emitter Voltage VCEO
- 60V
- Emitter-Base Voltage VEBO
- 5V
- DC Current Gain
- 750
- Pd - Power Dissipation
- 40W
- Current - Collector(Ic)
- 4A
- type
- NPN
- Vce Saturation(VCE(sat))
- 2.5V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 1.74 g
Overview
These devices are fabricated using planar substrate island technology, featuring a monolithic Darlington configuration.
Applications
- Linear and switching industrial equipment
Key features
- Good hFE linearity
- High fT frequency
- Monolithic Darlington configuration with integrated anti-parallel collector-emitter diode
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | BD677#C50229441DDF · TO-126 | DDF | TO-126 | 210 | ₹22.09 · 210 in stock | View |
 | BD681#C50229437DDF · TO-126 | DDF | TO-126 | 5 | ₹21.33 · 5 in stock | View |
 | BD681#C703688ST · SOT-32-3 | ST | SOT-32-3 | 6 | ₹57.68 · 6 in stock | View |
 | BD679AS#C900824onsemi · TO-126-3 | onsemi | TO-126-3 | 10 | ₹213.44 · 10 in stock | View |
 | BD679#C2970099ST · SOT-32-3 | ST | SOT-32-3 | 101 | ₹81.71 · 101 in stock | View |
