NexperiaDatasheet (PDF)
BZX8850S-C3V0-QYL
1 Independent 2.85V~3.15V 3V SOD-882 Single Zener Diodes RoHS
SOD-882ROHS3 CompliantActive
DIODE ZENER 3V 365mW SOD-882
- Manufacturer
- Nexperia
- Manufacturer part #
- BZX8850S-C3V0-QYL
- Store part #
- C3738602
- Package / case
- SOD-882
- Category
- Single Zener Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,000 in stock
#C3738602
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹43.47 | ₹217.35 |
| 50+ | ₹33.95 | ₹1,697.50 |
| 150+ | ₹29.87 | ₹4,480.50 |
| 500+ | ₹24.78 | ₹12,390.00 |
| 2,500+ | ₹22.52 | ₹56,300.00 |
| 5,000+ | ₹21.15 | ₹1,05,750.00 |
5 × ₹43.47
₹217.35
excl. GST
₹256.47 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 10,000 per reel
BZX8850S-C3V0-QYL
₹217.35 for 5 + GST
Specifications
- Diode Configuration
- 1 Independent
- Tolerance
- ±5%
- Pd - Power Dissipation
- 365mW
- Reverse Leakage Current (Ir)
- 800nA@1V
- Zener Voltage(Range)
- 2.85V~3.15V
- Zener Voltage(Nom)
- 3V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 10,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 8.4 g
Overview
Low- current voltage regulator diodes in an ultra small SOD882BD (DFN1006BD- 2) leadless Surface- Mounted Device (SMD) plastic package with side- wettable flanks.
Applications
- Low-current general regulation functions
Key features
- Total power dissipation: ≤ 365 mW
- Tolerance series: approximately ± 5%
- Working voltage range: nominal 1.8 V to 75 V
- Specified at a low test current (50 μA), ideal for low bias and portable battery-powered applications
- Qualified according to AEC-Q101 and recommended for use in automotive applications
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | BZX8850S-C3V0YL#C3733050Nexperia · SOD-882 | Nexperia | SOD-882 | 500 | ₹55.17 · 500 in stock | View |
 | BZX884-C3V0,315#C551234Nexperia · SOD-882 | Nexperia | SOD-882 | 10,000 | ₹5.83 · 10,000 in stock | View |
 | PZU3.0BL,315#C553691Nexperia · DFN1006-2 | Nexperia | DFN1006-2 | 95 | ₹22.44 · 95 in stock | View |
 | BZT52C3V0LP-7#C2983693DIODES · X1-DFN1006-2 | DIODES | X1-DFN1006-2 | 40 | ₹8.84 · 40 in stock | View |
 | AD-DW52C3V0LED02#C7472358JSCJ · WBFBP-02C | JSCJ | WBFBP-02C | 9,520 | ₹4.19 · 9,520 in stock | View |
