HXY MOSFETDatasheet (PDF)
C3D08065E-TR-HXY
1 Independent 650V 1.42V@6A 22.3A TO-252-2L Single Diodes
TO-252-2LRoHSActive
- Manufacturer
- HXY MOSFET
- Manufacturer part #
- C3D08065E-TR-HXY
- Store part #
- C51896341
- Package / case
- TO-252-2L
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
200 in stock
#C51896341
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹124.45 | ₹124.45 |
| 10+ | ₹121.64 | ₹1,216.40 |
| 30+ | ₹119.90 | ₹3,597.00 |
| 100+ | ₹117.96 | ₹11,796.00 |
1 × ₹124.45
₹124.45
excl. GST
₹146.85 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
C3D08065E-TR-HXY
₹124.45 for 1 + GST
Specifications
- Diode Configuration
- 1 Independent
- Operating Junction Temperature Range
- -55℃~+175℃
- Voltage - DC Reverse (Vr) (Max)
- 650V
- Voltage - Forward(Vf@If)
- 1.42V@6A
- Reverse Leakage Current (Ir)
- 50uA@650V
- Current - Rectified
- 22.3A
- Non-Repetitive Peak Forward Surge Current
- 60A
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.392 g
Overview
Applications
- Switch-mode power supplies
- Power factor correction
- Motor drives
Key features
- 650V Schottky rectifier
- Zero reverse recovery current
- Zero forward recovery voltage
- High-frequency operation
- Temperature-independent switching behavior
- Extremely fast switching speed
- Positive temperature coefficient of VF
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | S3D08065E-HXY#C51896309HXY MOSFET · TO-252-2L | HXY MOSFET | TO-252-2L | 38 | ₹136.96 · 38 in stock | View |
 | HC1D08065E#C41428786HXY MOSFET · TO-252-2L | HXY MOSFET | TO-252-2L | 136 | ₹220.35 · 136 in stock | View |
 | C3D02060E-TR-HXY#C53468040HXY MOSFET · TO-252-2L | HXY MOSFET | TO-252-2L | 96 | ₹109.50 · 96 in stock | View |
 | DSC08065D1-HXY#C53468057HXY MOSFET · TO-252-2L | HXY MOSFET | TO-252-2L | 49 | ₹253.35 · 49 in stock | View |
 | FFD08S60S-F085-HXY#C53468074HXY MOSFET · TO-252-2L | HXY MOSFET | TO-252-2L | 46 | ₹101.18 · 46 in stock | View |
