BOURNSDatasheet (PDF)
CD214A-B160R
Diode 60V 1A SMD
SMA(DO-214AC)ROHS3 CompliantActive
DIODE SCHOTTKY 60V SMD
- Manufacturer
- BOURNS
- Manufacturer part #
- CD214A-B160R
- Store part #
- C3757766
- Package / case
- SMA(DO-214AC)
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
35 in stock
#C3757766
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹30.40 | ₹152.00 |
| 50+ | ₹23.93 | ₹1,196.50 |
| 150+ | ₹21.15 | ₹3,172.50 |
| 500+ | ₹17.69 | ₹8,845.00 |
| 3,000+ | ₹16.15 | ₹48,450.00 |
| 6,000+ | ₹15.23 | ₹91,380.00 |
5 × ₹30.40
₹152.00
excl. GST
₹179.36 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
CD214A-B160R
₹152.00 for 5 + GST
Specifications
- Diode Configuration
- 1 Independent
- Operating Junction Temperature Range
- -55℃~+125℃
- Voltage - DC Reverse (Vr) (Max)
- 60V
- Voltage - Forward(Vf@If)
- 700mV@1A
- Reverse Leakage Current (Ir)
- 200uA@60V
- Non-Repetitive Peak Forward Surge Current
- 30A
- Current - Rectified
- 1A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.029 g
Overview
Bourns offers Schottky Rectifier Diodes for rectification applications, in a compact chip package compatible with DO- 214AC (SMA) size format. The Schottky Rectifier Diodes offer a forward current of 1 A with a choice of repetitive peak reverse voltage of 20V up to 100V
Applications
- Switch Mode Power Supplies
- Portable equipment batteries
- High frequency rectification
- DC/DC Converters
- Telecommunications
Key features
- RoHS compliant
- Low profile
- Low power loss, high efficiency
- UL 94V-0 classification
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | B160#C54529438GOODWORK · SMA | GOODWORK | SMA | 3,860 | ₹5.04 · 3,860 in stock | View |
 | SS16#C3014006FOSAN · SMA(DO-214AC) | FOSAN | SMA(DO-214AC) | 11,750 | ₹2.17 · 11,750 in stock | View |
 | B160-E3/5AT#C144852VISHAY · SMA(DO-214AC) | VISHAY | SMA(DO-214AC) | 100 | ₹11.25 · 100 in stock | View |
 | SS36A#C2915227WEIDA · SMA(DO-214AC) | WEIDA | SMA(DO-214AC) | 330 | ₹8.14 · 330 in stock | View |
 | B160AE-13#C6128331DIODES · SMA | DIODES | SMA | 4,030 | ₹10.93 · 4,030 in stock | View |
