PANASONIC

EEEFN1H470XP

47uF ±20% 50V Aluminum Electrolytic Capacitors 2000hrs@105℃

SMD,D6.3xL7.7mmROHS3 CompliantActive

CAP ALUM 47uF ±20% 50V SMD

Manufacturer: PANASONIC
Manufacturer part #: EEEFN1H470XP
Store part #: C494853
Package / case: SMD,D6.3xL7.7mm
Category: Aluminum Electrolytic Capacitors
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

275 in stock

#C494853

Stock & price checked 9 days ago

Quantity	Unit price	Pack price
5+	₹31.12	₹155.60
50+	₹24.90	₹1,245.00
150+	₹22.23	₹3,334.50
900+	₹18.27	₹16,443.00
2,700+	₹16.79	₹45,333.00
5,400+	₹15.90	₹85,860.00

Quantity (min 5, multiples of 5)

5 × ₹31.12

₹155.60

excl. GST

₹183.61 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 900 per reel

EEEFN1H470XP

₹155.60 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Tolerance: ±20%
Voltage Rating: 50V
Lifetime: 2000hrs@105℃
Capacitance: 47uF
Ripple Current: 195mA@100kHz
Polarity type: Polarized
Operating Temperature: -55℃~+105℃
Equivalent Series Resistance(ESR): 680mΩ@100kHz

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 900 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.787 g

Overview

SMD aluminum electrolytic capacitors. FN series 6.3V to 50V supports high-temperature lead-free reflow soldering; 63V to 100V supports standard lead-free reflow soldering.

Key features

Durability: 2000 hours at 105°C
Wide voltage range: 6.3V to 100V
High capacitance: 20% to 80% higher than FK series
Vibration-proof products available on request (diameter ≥6.3mm, guaranteed 30G)
AEC-Q200 compliant
RoHS compliant

Alternatives

Similar parts — check the datasheet before substituting.

	Manufacturer	Package	Stock	Price from (excl. GST)	Action
EEEFN1H470XV#C497608PANASONIC · SMD,D6.3xL7.7mm	PANASONIC	SMD,D6.3xL7.7mm	3	₹90.55 · 3 in stock	View
UUD1H470MCL1GS#C445256Nichicon · SMD,D6.3xL7.7mm	Nichicon	SMD,D6.3xL7.7mm	1,955	₹37.28 · 1,955 in stock	View
UCZ1H470MCS6GS#C2163359Nichicon · SMD,D6.3xL7.7mm	Nichicon	SMD,D6.3xL7.7mm	1,989	₹80.49 · 1,989 in stock	View
UWD1H470MCL1GS#C1952685Nichicon · SMD,D6.3xL7.7mm	Nichicon	SMD,D6.3xL7.7mm	2,310	₹28.62 · 2,310 in stock	View
EEEFK1H470XP#C168842PANASONIC · SMD,D6.3xL7.7mm	PANASONIC	SMD,D6.3xL7.7mm	13,995	₹42.03 · 13,995 in stock	View
