PANASONIC

EEEFNH820XUP

82uF ±20% 50V Aluminum Electrolytic Capacitors 2000hrs@105℃

SMD,D6.3xL7.7mmROHS3 CompliantActive

CAP ALUM 82uF ±20% 50V SMD

Manufacturer: PANASONIC
Manufacturer part #: EEEFNH820XUP
Store part #: C494855
Package / case: SMD,D6.3xL7.7mm
Category: Aluminum Electrolytic Capacitors
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

440 in stock

#C494855

Stock & price checked 9 days ago

Quantity	Unit price	Pack price
5+	₹46.64	₹233.20
50+	₹37.02	₹1,851.00
150+	₹32.90	₹4,935.00
900+	₹27.76	₹24,984.00
2,700+	₹25.47	₹68,769.00
5,400+	₹24.11	₹1,30,194.00

Quantity (min 5, multiples of 5)

5 × ₹46.64

₹233.20

excl. GST

₹275.18 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 900 per reel

EEEFNH820XUP

₹233.20 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Tolerance: ±20%
Voltage Rating: 50V
Lifetime: 2000hrs@105℃
Capacitance: 82uF
Ripple Current: 195mA@100kHz
Polarity type: Polarized
Operating Temperature: -55℃~+105℃
Equivalent Series Resistance(ESR): 680mΩ@100kHz

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 900 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.56 g

Overview

SMD aluminum electrolytic capacitors. FN series 6.3V to 50V supports high-temperature lead-free reflow soldering; 63V to 100V supports standard lead-free reflow soldering.

Key features

Durability: 2000 hours at 105°C
Wide voltage range: 6.3V to 100V
High capacitance: 20% to 80% higher than FK series
Vibration-proof products available on request (diameter ≥6.3mm, guaranteed 30G)
AEC-Q200 compliant
RoHS compliant

Alternatives

Similar parts — check the datasheet before substituting.

	Manufacturer	Package	Stock	Price from (excl. GST)	Action
EEE-FNH820XUL#C1881536PANASONIC · SMD,D6.3xL7.7mm	PANASONIC	SMD,D6.3xL7.7mm	244	₹129.48 · 244 in stock	View
EEE-FKH820XSL#C1881521PANASONIC · SMD,D6.3xL7.7mm	PANASONIC	SMD,D6.3xL7.7mm	On request	₹29.03 · 0 in stock	View
EEEFKH820XSP#C413641PANASONIC · SMD,D6.3xL7.7mm	PANASONIC	SMD,D6.3xL7.7mm	On request	₹31.46 · 0 in stock	View
EEE-FKH820XSV#C2164270PANASONIC · SMD,D6.3xL8mm	PANASONIC	SMD,D6.3xL8mm	On request	₹37.88 · 0 in stock	View
EEEFNH820XUV#C540955PANASONIC · SMD,D6.3xL8mm	PANASONIC	SMD,D6.3xL8mm	On request	₹110.07 · 0 in stock	View
