DIODESDatasheet (PDF)
ES2BA-13-F
25ns 100V 920mV@2A 2A SMA Single Diodes RoHS
SMAROHS CompliantActive
Diode 100V 2A SMA
- Manufacturer
- DIODES
- Manufacturer part #
- ES2BA-13-F
- Store part #
- C156286
- Package / case
- SMA
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
140 in stock
#C156286
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹52.95 | ₹264.75 |
| 50+ | ₹42.27 | ₹2,113.50 |
| 150+ | ₹37.71 | ₹5,656.50 |
| 500+ | ₹31.99 | ₹15,995.00 |
| 2,500+ | ₹26.51 | ₹66,275.00 |
| 5,000+ | ₹24.99 | ₹1,24,950.00 |
5 × ₹52.95
₹264.75
excl. GST
₹312.40 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
ES2BA-13-F
₹264.75 for 5 + GST
Specifications
- Reverse Recovery Time (trr)
- 25ns
- Operating Junction Temperature Range
- -55℃~+150℃
- Voltage - DC Reverse (Vr) (Max)
- 100V
- Voltage - Forward(Vf@If)
- 920mV@2A
- Reverse Leakage Current (Ir)
- 5uA@100V
- Non-Repetitive Peak Forward Surge Current
- 50A
- Current - Rectified
- 2A
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.148 g
Overview
Key features
- Glass Passivated Die Construction
- Super-Fast Recovery Time For High Efficiency
- Surge Overload Rating to 50A Peak
- Ideally Suited for Automated Assembly
- Lead Free Finish/RoHS Compliant
- Green Molding Compound (No Halogen and Antimony)
