DIODESDatasheet (PDF)
FUS1ME
75ns 1 Independent 1kV 1.7V@1A 1A DO-219AA Single Diodes RoHS
DO-219AAROHS3 CompliantActive
- Manufacturer
- DIODES
- Manufacturer part #
- FUS1ME
- Store part #
- C17591601
- Package / case
- DO-219AA
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
170 in stock
#C17591601
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹56.56 | ₹282.80 |
| 50+ | ₹45.72 | ₹2,286.00 |
| 150+ | ₹41.08 | ₹6,162.00 |
| 500+ | ₹35.30 | ₹17,650.00 |
| 2,500+ | ₹32.72 | ₹81,800.00 |
| 5,000+ | ₹31.17 | ₹1,55,850.00 |
5 × ₹56.56
₹282.80
excl. GST
₹333.70 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 10,000 per reel
FUS1ME
₹282.80 for 5 + GST
Specifications
- Reverse Recovery Time (trr)
- 75ns
- Diode Configuration
- 1 Independent
- Operating Junction Temperature Range
- -55℃~+150℃
- Voltage - DC Reverse (Vr) (Max)
- 1kV
- Voltage - Forward(Vf@If)
- 1.7V@1A
- Reverse Leakage Current (Ir)
- 5uA@1000V
- Non-Repetitive Peak Forward Surge Current
- 30A
- Current - Rectified
- 1A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 10,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.074 g
Overview
Key features
- Fast switching for high efficiency
- Surface mount applications
- Glass passivated die
- Low reverse leakage current
- Low forward voltage drop
- High current carrying capability
- AEC-Q101 Rev_C compliant
- Lead-free finish; RoHS compliant
- Halogen and antimony free, "Green" device
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | P1N4007W#C5162525Shanghai Prisemi Elec · SOD-123FL | Shanghai Prisemi Elec | SOD-123FL | 550 | ₹1.69 · 550 in stock | View |
 | RS1MSWFMQ-7#C19950433DIODES · SOD-123F | DIODES | SOD-123F | 20 | ₹90.28 · 20 in stock | View |
| HS1MLW#C17460100Taiwan Semiconductor · SOD-123W | Taiwan Semiconductor | SOD-123W | On request | ₹8.86 · 0 in stock | View | |
| HS1MLWH#C19852234Taiwan Semiconductor · SOD-123W | Taiwan Semiconductor | SOD-123W | On request | ₹8.86 · 0 in stock | View | |
| RS1MLWH#C19854045Taiwan Semiconductor · SOD-123W | Taiwan Semiconductor | SOD-123W | On request | ₹9.92 · 0 in stock | View | |
