DIODESDatasheet (PDF)
GDZ4V3LP3-7
Zener Diode Independent 4.3V 250mW Surface Mount X3-DFN0603-2
X3-DFN0603-2ROHS3 CompliantActive
DIODE ZENER 4.3V 250mW X3-DFN0603-2
- Manufacturer
- DIODES
- Manufacturer part #
- GDZ4V3LP3-7
- Store part #
- C5244926
- Package / case
- X3-DFN0603-2
- Category
- Single Zener Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
40 in stock
#C5244926
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹6.89 | ₹68.90 |
| 100+ | ₹5.52 | ₹552.00 |
| 300+ | ₹4.83 | ₹1,449.00 |
| 1,000+ | ₹4.31 | ₹4,310.00 |
| 5,000+ | ₹3.89 | ₹19,450.00 |
| 10,000+ | ₹3.69 | ₹36,900.00 |
10 × ₹6.89
₹68.90
excl. GST
₹81.30 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 10,000 per reel
GDZ4V3LP3-7
₹68.90 for 10 + GST
Specifications
- Diode Configuration
- 1 Independent
- Operating Junction Temperature Range
- -55℃~+150℃
- Pd - Power Dissipation
- 250mW
- Reverse Leakage Current (Ir)
- 5uA@1V
- Zener Voltage(Range)
- 4.08V~4.53V
- Zener Voltage(Nom)
- 4.3V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 10,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.018 g
Overview
Key features
- Ultra-Small Leadless Surface Mount Package (0.6 x 0.3 mm)
- Ultra-Low Profile Package (0.3 mm)
- Ideally Suited for Automated Assembly Processes
- Low Leakage Current, Suitable for Battery-Powered Applications
- Totally Lead-Free & Fully RoHS Compliant
- Halogen and Antimony Free, "Green" Device
- Qualified to AEC-Q101 Standards for High Reliability
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| NZD3V9MUT5G#C3735551onsemi · X3DFN2(0.3x0.6) | onsemi | X3DFN2(0.3x0.6) | 855 | ₹14.21 · 855 in stock | View | |
| NZD4V3MUT5G#C3732226onsemi · X3DFN2(0.3x0.6) | onsemi | X3DFN2(0.3x0.6) | On request | ₹4.84 · 0 in stock | View | |
 | GDZ3V9LP3-7#C5244924DIODES · X3-DFN0603-2 | DIODES | X3-DFN0603-2 | On request | ₹9.41 · 0 in stock | View |
| NZD4V7MUT5G#C3739326onsemi · X3DFN2(0.3x0.6) | onsemi | X3DFN2(0.3x0.6) | On request | ₹5.34 · 0 in stock | View | |
