VISHAYDatasheet (PDF)
GL41A-E3/97
Diode 50V 1A Surface Mount DO-213AB
DO-213ABROHS3 CompliantActive
DIODE STANDARD 50V 1A DO-213AB
- Manufacturer
- VISHAY
- Manufacturer part #
- GL41A-E3/97
- Store part #
- C2980315
- Package / case
- DO-213AB
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,630 in stock
#C2980315
Stock & price checked 12 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹40.67 | ₹203.35 |
| 50+ | ₹31.14 | ₹1,557.00 |
| 150+ | ₹27.07 | ₹4,060.50 |
| 500+ | ₹21.96 | ₹10,980.00 |
| 2,500+ | ₹16.67 | ₹41,675.00 |
| 5,000+ | ₹15.32 | ₹76,600.00 |
5 × ₹40.67
₹203.35
excl. GST
₹239.95 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
GL41A-E3/97
₹203.35 for 5 + GST
Specifications
- Diode Configuration
- 1 Independent
- Operating Junction Temperature Range
- -65℃~+175℃
- Voltage - DC Reverse (Vr) (Max)
- 50V
- Voltage - Forward(Vf@If)
- 1.1V@1A
- Reverse Leakage Current (Ir)
- 100uA@50V
- Non-Repetitive Peak Forward Surge Current
- 30A
- Current - Rectified
- 1A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.18 g
Overview
Applications
- For use in general purpose rectification of power supplies, inverters, converters and freewheeling diodes for consumer, automotive and telecommunication.
Key features
- Superectifier structure for high reliability condition
- Ideal for automated placement
- Low forward voltage drop e3
- Low leakage current RoHS
- High forward surge capability COMPLIANT
- Meets MSL level 1, per J - STD - 020, LF maximum peak of 250 ℃
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | GL41B-E3/96#C3008971VISHAY · DO-213AB | VISHAY | DO-213AB | 835 | ₹28.17 · 835 in stock | View |
 | 1N6479-E3/96#C511505VISHAY · DO-213AB | VISHAY | DO-213AB | 45 | ₹29.77 · 45 in stock | View |
 | BYM10-400-E3/96#C2984667VISHAY · DO-213AB | VISHAY | DO-213AB | 65 | ₹36.50 · 65 in stock | View |
 | GL41G-E3/96#C3151630VISHAY · DO-213AB | VISHAY | DO-213AB | 15 | ₹23.31 · 15 in stock | View |
 | BYM10-400-E3/97#C5346031VISHAY · DO-213AB | VISHAY | DO-213AB | 20 | ₹130.14 · 20 in stock | View |
