IPD70N10S3-12-VB
N-Channel 100V 85A 176W Surface Mount TO-252
TO-252RoHSActive
MOSFET N-CH 100V 85A TO-252
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- IPD70N10S3-12-VB
- Store part #
- C7463544
- Package / case
- TO-252
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
20 in stock
#C7463544
Stock & price checked 12 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹133.81 | ₹133.81 |
| 10+ | ₹109.86 | ₹1,098.60 |
| 30+ | ₹97.89 | ₹2,936.70 |
| 100+ | ₹85.92 | ₹8,592.00 |
| 500+ | ₹71.64 | ₹35,820.00 |
| 1,000+ | ₹68.07 | ₹68,070.00 |
1 × ₹133.81
₹133.81
excl. GST
₹157.90 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
IPD70N10S3-12-VB
₹133.81 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 100V
- Current - Continuous Drain(Id)
- 85A
- Ciss-Input Capacitance
- 4nF
- Pd - Power Dissipation
- 176W
- Reverse Transfer Capacitance (Crss)
- 205pF
- RDS(on)
- 8.5mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 160nC@10V
- Gate Threshold Voltage (Vgs(th))
- 4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.38 g
Overview
Applications
- Primary Side Switch Isolated DC/DC Converter
Key features
- TrenchFET Power MOSFET
- 100 % Rg Tested
- 100 % UIS Tested
