IS31FL3193-DLS2-TR

IS31FL3193 is a 3-channel fun LED driver which features two-dimensional auto breathing mode. It has One Shot Programming mode and PWM Control mode for RGB lighting effects. The maximum output current can be adjusted in 5 levels (5mA~42mA). In PWM Control mode, the PWM duty cycle of each output can be independently programmed and controlled in 256 steps to simplify color mixing. In One Shot Programming mode, the timing characteristics for output current - current rising, holding, falling and off time, can be adjusted individually so that each output can independently maintain a pre-established pattern achieving mixing color breathing or a single color breathing without requiring any additional interface activity, thus saving valuable system resources. IS31FL3193 is available in DFN-10 (3mm×3mm). It operates from 2.7V to 5.5V over the temperature range of -40°C to +85°C.

Applications

• Mobile phones and other hand-held devices for LED display
• LED in home appliances

Key features

• One group RGB, single color LED breathing system-free pre-established pattern
• 3 independently controlled automatic and semiautomatic breathing system-free pre-established pattern
• I2C interface, automatic address increment function
• 3 independently controlled outputs of 256 PWM steps
• 2.7V to 5.5V supply voltage
• 5 levels programmable output current
• Over-temperature protection
• Operating temperature TA = -40°C~+85°C
• DFN-10 (3mm×3mm) package
