L78L15ABUTR
15V Positive Fixed SOT-89-3 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
SOT-89-3ROHS3 CompliantActive
0.1A Positive Voltage Regulator
- Manufacturer
- ST
- Manufacturer part #
- L78L15ABUTR
- Store part #
- C81364
- Package / case
- SOT-89-3
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
39,385 in stock
#C81364
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹23.75 | ₹118.75 |
| 50+ | ₹18.72 | ₹936.00 |
| 150+ | ₹16.55 | ₹2,482.50 |
| 500+ | ₹13.85 | ₹6,925.00 |
| 2,500+ | ₹11.18 | ₹27,950.00 |
| 5,000+ | ₹10.46 | ₹52,300.00 |
5 × ₹23.75
₹118.75
excl. GST
₹140.13 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
L78L15ABUTR
₹118.75 for 5 + GST
Specifications
- Output Voltage
- 15V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+125℃@(Tj)
- Supply Current (Iq)
- 6.5mA
- Output Configuration
- Positive
- Operating Voltage
- 35V
- Output Current
- 100mA
- Features
- Short Circuit Protection;Over Current Protection;Thermal shutdown
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.253 g
Overview
The L78L series of three-terminal positive regulators employ internal current limiting and thermal shutdown, making them essentially indestructible. If adequate heat-sink is provided, they can deliver up to 100 mA output current. They are intended as fixed voltage regulators in a wide range of applications including local or oncard regulation for elimination of noise and distribution problems associated with single-point regulation. In addition, they can be used with power pass elements to make high-current voltage regulators. The L78L series used as Zener diode/resistor combination replacement, offers e improvement along with lower quiescent current and lower noise.
Key features
- Output current up to 100 mA
- Output voltages of 3.3; 5; 6; 8; 9; 10; 12; 15; 18; 24 V
- Thermal overload protection
- Short-circuit protection
- No external components are required
- Available in either ± 4% (A) or ± 8% (C) selection
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | PJ78L15SQ#C411742PJSEMI · SOT-89-3 | PJSEMI | SOT-89-3 | 360 | ₹9.17 · 360 in stock | View |
 | SL78L15#C880738Slkor · SOT-89-3 | Slkor | SOT-89-3 | 520 | ₹9.26 · 520 in stock | View |
 | 78L15K#C22400123Shikues · SOT-89 | Shikues | SOT-89 | 250 | ₹7.33 · 250 in stock | View |
 | 78L15#C42395202KUU · SOT-89 | KUU | SOT-89 | 800 | ₹5.49 · 800 in stock | View |
 | 78L15#C5692991UMW · SOT-89 | UMW | SOT-89 | 26,120 | ₹5.95 · 26,120 in stock | View |
