L78L15ACUTR
15V Positive Fixed SOT-89-3 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
SOT-89-3ROHS3 CompliantActive
0.1A Positive Voltage Regulator
- Manufacturer
- ST
- Manufacturer part #
- L78L15ACUTR
- Store part #
- C115285
- Package / case
- SOT-89-3
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,940 in stock
#C115285
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹34.78 | ₹173.90 |
| 50+ | ₹27.81 | ₹1,390.50 |
| 150+ | ₹24.82 | ₹3,723.00 |
| 500+ | ₹21.09 | ₹10,545.00 |
| 2,500+ | ₹19.17 | ₹47,925.00 |
| 5,000+ | ₹18.16 | ₹90,800.00 |
5 × ₹34.78
₹173.90
excl. GST
₹205.20 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
L78L15ACUTR
₹173.90 for 5 + GST
Specifications
- Output Voltage
- 15V
- Number of Outputs
- 1
- Operating Temperature
- 0℃~+125℃@(Tj)
- Supply Current (Iq)
- 6.5mA
- Output Configuration
- Positive
- Operating Voltage
- 30V
- Output Current
- 100mA
- Features
- Thermal shutdown;Short Circuit Protection;Over Current Protection
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.253 g
Overview
The L78L series of three-terminal positive regulators employ internal current limiting and thermal shutdown, making them essentially indestructible. If adequate heat-sink is provided, they can deliver up to 100 mA output current. They are intended as fixed voltage regulators in a wide range of applications including local or oncard regulation for elimination of noise and distribution problems associated with single-point regulation. In addition, they can be used with power pass elements to make high-current voltage regulators. The L78L series used as Zener diode/resistor combination replacement, offers e improvement along with lower quiescent current and lower noise.
Key features
- Output current up to 100 mA
- Output voltages of 3.3; 5; 6; 8; 9; 10; 12; 15; 18; 24 V
- Thermal overload protection
- Short-circuit protection
- No external components are required
- Available in either ± 4% (A) or ± 8% (C) selection
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | 78L15#C5364318LGE · SOT-89 | LGE | SOT-89 | 210 | ₹11.97 · 210 in stock | View |
 | CJ78L15#C8627JSCJ · SOT-89-3 | JSCJ | SOT-89-3 | 9,290 | ₹11.50 · 9,290 in stock | View |
 | WG78L15#C17702385Wild Goose · SOT-89 | Wild Goose | SOT-89 | 780 | ₹7.70 · 780 in stock | View |
 | 78L15#C3025160GOODWORK · SOT-89-3 | GOODWORK | SOT-89-3 | 6,980 | ₹6.01 · 6,980 in stock | View |
 | 78L15#C5364241Guangdong Hottech · SOT-89 | Guangdong Hottech | SOT-89 | 990 | ₹7.86 · 990 in stock | View |
