L8550HRLT1G
Bipolar (BJT) Transistor PNP 25V 1500mA 225mW Surface Mount SOT-23
SOT-23RoHSActive
TRANS PNP 25V 1500mA SOT-23
- Manufacturer
- LRC
- Manufacturer part #
- L8550HRLT1G
- Store part #
- C67247
- Package / case
- SOT-23
- Category
- Single Bipolar Transistors
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
280 in stock
#C67247
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹2.29 | ₹45.80 |
| 200+ | ₹1.77 | ₹354.00 |
| 600+ | ₹1.48 | ₹888.00 |
| 3,000+ | ₹1.19 | ₹3,570.00 |
| 9,000+ | ₹1.05 | ₹9,450.00 |
| 21,000+ | ₹0.9658 | ₹20,281.80 |
20 × ₹2.29
₹45.80
excl. GST
₹54.04 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
L8550HRLT1G
₹45.80 for 20 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Current - Collector Cutoff
- 150nA
- Collector - Emitter Voltage VCEO
- 25V
- Emitter-Base Voltage VEBO
- 5V
- DC Current Gain
- 100
- Pd - Power Dissipation
- 225mW
- Current - Collector(Ic)
- 1.5A
- Number
- 1 PNP
- type
- PNP
- Vce Saturation(VCE(sat))
- 500mV
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 0.031 g
Overview
Key features
- High current capacity in compact package.
- Epitaxial planar type.
- PNP complement: L8550H
- We declare that the material of product compliance with RoHS requirements.
- S- Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC-Q101 Qualified and PPAP Capable.
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | L8550HQLT1G#C39282LRC · SOT-23 | LRC | SOT-23 | 16,800 | ₹2.14 · 16,800 in stock | View |
 | L8550HPLT1G#C5137507LRC · SOT-23 | LRC | SOT-23 | 2,280 | ₹3.45 · 2,280 in stock | View |
 | LH8550QLT1G#C97290LRC · SOT-23 | LRC | SOT-23 | 1,14,600 | ₹3.89 · 1,14,600 in stock | View |
 | LBSS5240LT1G#C92422LRC · SOT-23 | LRC | SOT-23 | 25,980 | ₹7.12 · 25,980 in stock | View |
