STDatasheet (PDF)
LD1117V18
1.8V Positive Fixed TO-220 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
TO-220ROHS3 CompliantDiscontinued
Adjustable and Fixed Low Dropout Positive Voltage Regulators
- Manufacturer
- ST
- Manufacturer part #
- LD1117V18
- Store part #
- C5267860
- Package / case
- TO-220
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
89 in stock
#C5267860
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹103.79 | ₹103.79 |
| 10+ | ₹84.63 | ₹846.30 |
| 50+ | ₹72.35 | ₹3,617.50 |
| 100+ | ₹63.09 | ₹6,309.00 |
| 500+ | ₹57.29 | ₹28,645.00 |
| 1,000+ | ₹54.48 | ₹54,480.00 |
1 × ₹103.79
₹103.79
excl. GST
₹122.47 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 50 per tube
LD1117V18
₹103.79 for 1 + GST
Specifications
- Output Voltage
- 1.8V
- Number of Outputs
- 1
- Operating Temperature
- 0℃~+125℃@(Tj)
- Supply Current (Iq)
- 10mA
- Output Configuration
- Positive
- Output Current
- 800mA
- Operating Voltage
- 15V
- Output Type
- Fixed
- Features
- Over Current Protection;Thermal shutdown
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Discontinued
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 2.75 g
Overview
The LD1117 is a low drop voltage regulator capable of delivering 800 mA of output current, available even in adjustable version (V = 1.25 - 3.3 V) and in fixed versions, offered the following output voltages: 1.2 V, 1.8 V, 2.5 V, 2.85 V, 3.3 V and 5.0 V. The device is supplied in: SOT - 223, DPAK, SO - 8 and TO - 220. The SOT - 223 and DPAK surface mount package optimize the thermal characteristics even offering a relevant space saving effect. High efficiency is assured by NPN pass transistor. In fact in this unlike than PNP one, the quiescent current flows mostly into the load. Only a very common 10 µF minimum capacitor is needed for stability. Laser trimming allows the regulator to reach very tight output voltage tolerance, within ± 1 % at 25 °C. The adjustable LD1117 is pin to pin compatible with the other standard.
Key features
- Low dropout voltage (1 V for 2.85 V device at 800 mA)
- Fixed output voltage of: 1.2 V, (V_REF = 1.25 V), 1.8 V, 2.5 V, 2.85 V, 3.3 V, 5.0 V
- Regulation accuracy: ± 1 % at 25 °C and 2 %
- Available in ± 1 % (at 25 °C) and 2 %
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | MC33269T-1.8/HG#C46614082HGSEMI · TO-220-3 | HGSEMI | TO-220-3 | 1,000 | ₹44.98 · 1,000 in stock | View |
 | LM1117T-1.8#C498324HGSEMI · TO-220-3 | HGSEMI | TO-220-3 | 610 | ₹42.16 · 610 in stock | View |
 | AMS1117-1.8V#C7380514MSKSEMI · SOT-223 | MSKSEMI | SOT-223 | 17,190 | ₹6.99 · 17,190 in stock | View |
| MIC39150-1.8WT#C641290MICROCHIP · TO-220 | MICROCHIP | TO-220 | On request | ₹1,157.98 · 0 in stock | View | |
| MIC39151-1.8WT#C641296MICROCHIP · TO-220-3 | MICROCHIP | TO-220-3 | On request | ₹229.90 · 0 in stock | View | |
