UMW
XC6206P332MRLinear Voltage Regulator IC Positive Fixed 1 Output 250mA SOT-23
From
₹2.53
18,64,000 in stock
HTCDatasheet (PDF)
LM317L
1.2V~37V Positive Adjustable TO-92-3 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
TO-92-3ROHS CompliantActive
Adjustable Voltage Regulator (Positive)
- Manufacturer
- HTC
- Manufacturer part #
- LM317L
- Store part #
- C126053
- Package / case
- TO-92-3
- Packaging
- Bag-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,035 in stock
#C126053
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹25.06 | ₹125.30 |
| 50+ | ₹19.79 | ₹989.50 |
| 150+ | ₹17.54 | ₹2,631.00 |
| 1,000+ | ₹14.12 | ₹14,120.00 |
| 2,000+ | ₹12.86 | ₹25,720.00 |
| 5,000+ | ₹12.11 | ₹60,550.00 |
5 × ₹25.06
₹125.30
excl. GST
₹147.85 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,000 per bag
LM317L
₹125.30 for 5 + GST
Specifications
- Output Voltage
- 1.2V~37V
- Number of Outputs
- 1
- Operating Temperature
- 0℃~+125℃
- Supply Current (Iq)
- 46uA
- Output Configuration
- Positive
- Operating Voltage
- 40V
- Output Current
- 100mA
- Features
- Thermal shutdown;Short Circuit Protection;Over Current Protection
- Output Type
- Adjustable
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Bag-packed
- Standard pack
- 1,000 / Bag
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.214 g
Overview
This monolithic integrated circuit is an adjustable 3-terminal positive voltage regulator designed to supply more than 100mA of load current with an output voltage adjustable over a 1.2 to 37V. It employs internal current limiting, thermal shut-down and safe area compensation.
Key features
- Output current in Excess of 100mA
- Output Adjustable Between 1.2V and 37V
- Internal Thermal-Overload Protection
- Internal Short-Circuit Current-Limiting
- Output Transistor Safe-Area Compensation
- Floating operation for high voltage applications
- Moisture Sensitivity Level 3
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | LM317LZ-AP#C2971145ST · TO-92 | ST | TO-92 | 86 | ₹98.97 · 86 in stock | View |
 | LM317LZ/LFT2#C2877243TI · TO-92-3 | TI | TO-92-3 | 98 | ₹99.03 · 98 in stock | View |
| LM317LBZRAG#C480787onsemi · TO-92 | onsemi | TO-92 | 41 | ₹79.67 · 41 in stock | View | |
 | LM317LBZG#C184354onsemi · TO-92-3 | onsemi | TO-92-3 | 246 | ₹55.70 · 246 in stock | View |
 | LM317LZ/NOPB#C27605TI · TO-92 | TI | TO-92 | 4,926 | ₹79.49 · 4,926 in stock | View |
