MICROCHIPDatasheet (PDF)
MIC5270YM5-TR
1.2V~14V Negative Adjustable SOT-23-5 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
SOT-23-5ROHS3 CompliantActive
uCap Negative Low-Dropout Regulator
- Manufacturer
- MICROCHIP
- Manufacturer part #
- MIC5270YM5-TR
- Store part #
- C220674
- Package / case
- SOT-23-5
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
44 in stock
#C220674
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹261.85 | ₹261.85 |
| 10+ | ₹222.52 | ₹2,225.20 |
| 30+ | ₹197.96 | ₹5,938.80 |
| 100+ | ₹172.76 | ₹17,276.00 |
| 500+ | ₹161.46 | ₹80,730.00 |
| 1,000+ | ₹156.46 | ₹1,56,460.00 |
1 × ₹261.85
₹261.85
excl. GST
₹308.98 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
MIC5270YM5-TR
₹261.85 for 1 + GST
Specifications
- Output Voltage
- 1.2V~14V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+125℃@(Tj)
- Supply Current (Iq)
- 100uA
- Output Configuration
- Negative
- Output Current
- 100mA
- Operating Voltage
- 16V
- Features
- Thermal shutdown;Over Current Protection
- Output Type
- Adjustable
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.043 g
Overview
The MIC5270 is a µCap 100mA negative regulator in a SOT - 23 - 5 package. With better than 2% initial accuracy, this regulator provides a very accurate supply voltage for applications that require a negative rail. The MIC5270 sinks 100mA of output current at very low dropout voltage (600mV maximum at 100mA of output current). The uCap regulator design is optimized to work with low - value, low - cost ceramic capacitors. The output typically requires only a capacitance for stability.
Applications
- GaAsFET bias
- Portable cameras and video recorders
- PDAs
- Battery - powered equipment
Key features
- Stable with ceramic or tantalum capacitor
- Low dropout voltage: 500mV @ 100mA
- Low ground current: 35µA @ Load = 100µA
- Tight initial accuracy: ±2%
- Tight load and line regulation
- Thermal shutdown
- Current limiting
- IttyBitty SOT - 23 - 5 packaging
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | MIC5271YM5-TR#C625971MICROCHIP · SOT-23-5 | MICROCHIP | SOT-23-5 | 30 | ₹376.43 · 30 in stock | View |
| MIC5271BM5#C3744552MICROCHIP · SOT-23-5 | MICROCHIP | SOT-23-5 | On request | ₹127.14 · 0 in stock | View | |
