MJD42CG
100V 15 6A 1 PNP PNP DPAK Single Bipolar Transistors RoHS
DPAKROHS3 CompliantActive
- Manufacturer
- onsemi
- Manufacturer part #
- MJD42CG
- Store part #
- C897478
- Package / case
- DPAK
- Category
- Single Bipolar Transistors
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
69 in stock
#C897478
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹164.22 | ₹164.22 |
| 10+ | ₹161.21 | ₹1,612.10 |
| 30+ | ₹159.28 | ₹4,778.40 |
| 100+ | ₹157.13 | ₹15,713.00 |
1 × ₹164.22
₹164.22
excl. GST
₹193.78 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 75 per tube
MJD42CG
₹164.22 for 1 + GST
Specifications
- Operating Temperature
- -65℃~+150℃
- Current - Collector Cutoff
- 50uA
- Transition frequency(fT)
- 3MHz
- Collector - Emitter Voltage VCEO
- 100V
- Emitter-Base Voltage VEBO
- 5V
- DC Current Gain
- 15
- Current - Collector(Ic)
- 6A
- Pd - Power Dissipation
- 1.75W
- Configuration
- Standalone
- Number
- 1 PNP
- type
- PNP
- Vce Saturation(VCE(sat))
- 1.5V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 75 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.899 g
Overview
Designed for general purpose amplifier and low speed switching applications.
Key features
- Lead Formed for Surface Mount Applications in Plastic Sleeves (No Suffix)
- Straight Lead Version in Plastic Sleeves (“1” Suffix)
- Electrically Similar to Popular TIP41 and TIP42 Series
- Epoxy Meets UL 94 V-0 @ 0.125 in
- NJV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q101 Qualified and PPAP Capable
- These Devices are Pb −Free and are RoHS Compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| MJD42CRLG#C900621onsemi · DPAK | onsemi | DPAK | 85 | ₹97.76 · 85 in stock | View | |
 | MJD42CRLG#C41421812JSMSEMI · TO-252 | JSMSEMI | TO-252 | 2,165 | ₹26.16 · 2,165 in stock | View |
 | MJD42C#C2891516JSCJ · TO-252-2L | JSCJ | TO-252-2L | 4,440 | ₹44.90 · 4,440 in stock | View |
| NJVMJD42CRLG#C900624onsemi · DPAK | onsemi | DPAK | On request | ₹75.70 · 0 in stock | View | |
 | MJD42C-QJ#C3198525Nexperia · DPAK | Nexperia | DPAK | On request | ₹56.43 · 0 in stock | View |
