NexperiaDatasheet (PDF)
MM5Z27VT5GF
1 Independent 26.46V~27.54V 27V SOD-523 Single Zener Diodes RoHS
SOD-523ROHS3 CompliantActive
- Manufacturer
- Nexperia
- Manufacturer part #
- MM5Z27VT5GF
- Store part #
- C3738358
- Package / case
- SOD-523
- Category
- Single Zener Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
95 in stock
#C3738358
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹23.07 | ₹115.35 |
| 50+ | ₹22.53 | ₹1,126.50 |
| 150+ | ₹22.19 | ₹3,328.50 |
| 500+ | ₹21.83 | ₹10,915.00 |
5 × ₹23.07
₹115.35
excl. GST
₹136.11 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
MM5Z27VT5GF
₹115.35 for 5 + GST
Specifications
- Diode Configuration
- 1 Independent
- Tolerance
- ±2%
- Pd - Power Dissipation
- 300mW
- Reverse Leakage Current (Ir)
- 50nA@18.9V
- Zener Voltage(Range)
- 26.46V~27.54V
- Zener Voltage(Nom)
- 27V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.249 g
Overview
General- purpose Zener diodes in an SOD523 (SC- 79) ultra small flat lead Surface- Mounted Device (SMD) plastic package.
Applications
- General regulation functions
Key features
- Non-repetitive peak reverse power dissipation: ≤ 40W
- Total power dissipation: ≤ 300mW
- Tolerance series: ± 2%
- Wide working voltage range: nominal 2.4V to 36V
- Low differential resistance
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | BZX585-B27,115#C550598Nexperia · SOD-523(SC-79) | Nexperia | SOD-523(SC-79) | 390 | ₹9.57 · 390 in stock | View |
 | EDZVFHT2R27B#C6239667ROHM · SC-79(SOD-523) | ROHM | SC-79(SOD-523) | 100 | ₹16.21 · 100 in stock | View |
 | EDZVT2R27B#C209636ROHM · SOD-523 | ROHM | SOD-523 | 14,860 | ₹3.47 · 14,860 in stock | View |
 | TPZ27VC-523#C46641682TECH PUBLIC · SOD-523 | TECH PUBLIC | SOD-523 | 2,400 | ₹2.37 · 2,400 in stock | View |
 | BZX584C27#C46641709TECH PUBLIC · SOD-523 | TECH PUBLIC | SOD-523 | 2,550 | ₹2.26 · 2,550 in stock | View |
