onsemiDatasheet (PDF)
NCP164CSNADJT1G
1.1V~4.5V Positive Adjustable TSOP-5 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
TSOP-5ROHS3 CompliantActive
300 mA LDO Regulator, Low Dropout Voltage, Ultra Low Noise, High PSRR with Power Good
- Manufacturer
- onsemi
- Manufacturer part #
- NCP164CSNADJT1G
- Store part #
- C892221
- Package / case
- TSOP-5
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
96 in stock
#C892221
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹140.07 | ₹140.07 |
| 10+ | ₹113.18 | ₹1,131.80 |
| 30+ | ₹99.74 | ₹2,992.20 |
| 100+ | ₹86.30 | ₹8,630.00 |
| 500+ | ₹78.28 | ₹39,140.00 |
| 1,000+ | ₹74.15 | ₹74,150.00 |
1 × ₹140.07
₹140.07
excl. GST
₹165.28 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
NCP164CSNADJT1G
₹140.07 for 1 + GST
Specifications
- Output Voltage
- 1.1V~4.5V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+150℃@(Tj)
- Supply Current (Iq)
- 30uA
- Output Configuration
- Positive
- Output Current
- 300mA
- Operating Voltage
- 5V
- Features
- Enable control;Operating status indication;Thermal shutdown;Output discharge;Over Current Protection
- Output Type
- Adjustable
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.47 g
Overview
The NCP164C is a 300 mA LDO, next generation of high PSRR, ultra−low noise and low dropout regulators with Power Good open collector output. Designed to meet the requirements of RF and sensitive analog circuits, the NCP164C device provides ultra−low noise, high PSRR and low quiescent current. The device also offer excellent load/line transients. The NCP164C is designed to work with a 1 μF input and a 1 μF output ceramic capacitor. It is available in industry standard TSOP−5, WDFN6 0.65P, 2 mm x 2 mm and DFNW8 0.65P, 3 mm×3 mm.
Applications
- Communication Systems
- In−Vehicle Networking
- Telematics, Infotainment and Clusters
- General Purpose Automotive
Key features
- Operating Input Voltage Range: 1.6 V to 5.0 V
- Available in Fixed Voltage Option: 1.2 V to 4.5 V
- Adjustable Version Reference Voltage: 1.1 V
- ±2% Accuracy Over Load and Temperature
- Ultra Low Quiescent Current Typ. 30 μA
- Standby Current: Typ. 0.1 μA
- Very Low Dropout: 110 mV at 300 mA for 3.3 V Variant
- Ultra High PSRR: Typ. 85 dB at 10 mA, f = 1 kHz
- Ultra Low Noise: 9 μVRMS (Fixed Version)
- Stable with a 1 μF Small Case Size Ceramic Capacitors
- Available in - TSOP - 5 3 mm x 1.5 mm x 1 mm CASE 483 ♦WDFN6 2 mm x 2 mm x 0.75 mm CASE 511BR ♦DFNW8 3 mm x 3 mm x 0.9 mm CASE 507AD
- These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
