onsemiDatasheet (PDF)
NCP302045MNTWG
Step-down type PQFN-31(5x5) Full, Half-Bridge (H Bridge) Drivers RoHS
PQFN-31(5x5)ROHS3 CompliantActive
- Manufacturer
- onsemi
- Manufacturer part #
- NCP302045MNTWG
- Store part #
- C892332
- Package / case
- PQFN-31(5x5)
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,075 in stock
#C892332
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹215.31 | ₹215.31 |
| 10+ | ₹177.36 | ₹1,773.60 |
| 30+ | ₹156.55 | ₹4,696.50 |
| 100+ | ₹133.13 | ₹13,313.00 |
| 500+ | ₹122.72 | ₹61,360.00 |
| 1,000+ | ₹117.96 | ₹1,17,960.00 |
1 × ₹215.31
₹215.31
excl. GST
₹254.07 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
NCP302045MNTWG
₹215.31 for 1 + GST
Specifications
- Synchronous Rectifier
- Yes
- Operating Temperature
- -40℃~+125℃
- Function
- Step-down type
- Features
- Operating status indication
- Number of Outputs
- 1
- Quiescent Current
- 400nA
- Topology
- Buck
- Switch Frequency
- 2MHz
- Voltage - Supply
- 4.5V~5.5V
- Switch tube (built-in/external)
- Built-in
- Output Current
- 45A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.11 g
Overview
The NCP302045 integrates a MOSFET driver, high-side MOSFET and low-side MOSFET into a single package. The driver and MOSFETs have been optimized for high-current DC−DC buck power conversion applications. The NCP302045 integrated solution greatly reduces package parasitics and board space compared to a discrete component solution.
Applications
- Desktop & Notebook Microprocessors
Key features
- Capable of Average Currents up to 45 A
- Capable of Switching at Frequencies up to 2 MHz
- Capable of Peak Currents up to 75 A
- Compatible with 3.3 V or 5 V PWM Input
- Responds Properly to 3-level PWM Inputs
- Option for Zero Cross Detection with 3-level PWM
- Internal Bootstrap Diode
- Undervoltage Lockout
- Supports Intel Power State 4
- Thermal Warning output
- Thermal Shutdown
