NE5532DR
38mA 2 500uV 9V/us 100dB 1uA 16mA 10MHz SOIC-8 Instrumentation, Op Amps, Buffer Amps RoHS
PopularSOIC-8ROHS3 CompliantActive
Dual Low-Noise Operational Amplifiers
- Manufacturer
- TI
- Manufacturer part #
- NE5532DR
- Store part #
- C7426
- Package / case
- SOIC-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,43,620 in stock
#C7426
Stock & price checked 29 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹14.37 | ₹71.85 |
| 50+ | ₹11.43 | ₹571.50 |
| 150+ | ₹9.92 | ₹1,488.00 |
| 500+ | ₹8.68 | ₹4,340.00 |
| 2,500+ | ₹8.26 | ₹20,650.00 |
| 5,000+ | ₹7.95 | ₹39,750.00 |
5 × ₹14.37
₹71.85
excl. GST
₹84.78 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
NE5532DR
₹71.85 for 5 + GST
Specifications
- Output Current
- 38mA
- Number of Channels
- 2
- Vos - Input Offset Voltage
- 500uV
- Slew Rate
- 9V/us
- Input Offset Current(Ios)
- 10nA
- Operating Temperature
- 0℃~+70℃
- Common Mode Rejection Ratio(CMRR)
- 100dB
- Ib - Input Bias Current
- 1uA
- Input Offset Voltage Drift(Vos TC)
- 5uV/℃
- Quiescent Current
- 16mA
- Gain Bandwidth Product
- 10MHz
- Features
- Built-in compensation
- Input Voltage Noise Density
- 5nV/√Hz@1kHz
- Dual Supply
- -15V~15V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.116 g
Overview
The NE5532, NE5532A, SA5532, and SA5532A are high-performance operational amplifiers combining excellent dc and ac characteristics. They feature very low noise, high output-drive capability, high unity-gain and maximum-output-swing bandwidths, low distortion, high slew rate, input-protection diodes, and output short-circuit protection. These operational amplifiers are compensated internally for unity-gain operation. These devices have specified maximum limits for equivalent input noise voltage.
Applications
- AV receivers
- Embedded PCs
- Netbooks
- Scalable video broadcast infrastructure platforms
- DVD recorders and players
- Multi-channel video transcoders
- Professional audio mixers
Key features
- Equivalent Input Noise Voltage: 5 nv/√Hz Typ at 1 kHz
- Unity-Gain Bandwidth: 10 MHz Typ
- Common-Mode Rejection Ratio: 100 dB Typ
- High DC Voltage Gain: 100 V/mV Typ
- Peak-to-Peak Output Voltage Swing 26 V Typ With Vcc± = ±15 V and RL = 600 Ω
- High Slew Rate: 9 V/μs Typ
