HXY MOSFETDatasheet (PDF)
NRVBA120ET3G-VF01-HXY
20V 1 Independent 550mV@1A 1A SMA Single Diodes
SMARoHSActive
- Manufacturer
- HXY MOSFET
- Manufacturer part #
- NRVBA120ET3G-VF01-HXY
- Store part #
- C52988596
- Package / case
- SMA
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
170 in stock
#C52988596
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹7.53 | ₹75.30 |
| 100+ | ₹6.01 | ₹601.00 |
| 300+ | ₹5.24 | ₹1,572.00 |
| 2,000+ | ₹4.66 | ₹9,320.00 |
| 4,000+ | ₹4.21 | ₹16,840.00 |
| 10,000+ | ₹3.97 | ₹39,700.00 |
10 × ₹7.53
₹75.30
excl. GST
₹88.85 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
NRVBA120ET3G-VF01-HXY
₹75.30 for 10 + GST
Specifications
- Voltage - DC Reverse (Vr) (Max)
- 20V
- Diode Configuration
- 1 Independent
- Operating Junction Temperature Range
- -50℃~+125℃
- Voltage - Forward(Vf@If)
- 550mV@1A
- Reverse Leakage Current (Ir)
- 500uA@20V
- Current - Rectified
- 1A
- Non-Repetitive Peak Forward Surge Current
- 30A
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.083 g
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | CMSH1-20MTR13-HXY#C52988594HXY MOSFET · SMA | HXY MOSFET | SMA | 180 | ₹44.80 · 180 in stock | View |
 | MBRA120ET3G-HXY#C52988595HXY MOSFET · SMA | HXY MOSFET | SMA | 150 | ₹9.91 · 150 in stock | View |
 | B140-13-F-HXY#C52988597HXY MOSFET · SMA | HXY MOSFET | SMA | 40 | ₹4.60 · 40 in stock | View |
 | B140Q-13-F-HXY#C52988598HXY MOSFET · SMA | HXY MOSFET | SMA | 180 | ₹11.15 · 180 in stock | View |
 | CMSH1-40MTR13-HXY#C52988599HXY MOSFET · SMA | HXY MOSFET | SMA | 127 | ₹96.14 · 127 in stock | View |
