OP07CDR
1 60uV 0.3V/us 120dB 1.8nA 400kHz SOIC-8 Instrumentation, Op Amps, Buffer Amps RoHS
SOIC-8ROHS3 CompliantActive
Precision Operational Amplifiers
- Manufacturer
- TI
- Manufacturer part #
- OP07CDR
- Store part #
- C7433
- Package / case
- SOIC-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,87,440 in stock
#C7433
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹16.99 | ₹84.95 |
| 50+ | ₹13.44 | ₹672.00 |
| 150+ | ₹11.62 | ₹1,743.00 |
| 500+ | ₹10.12 | ₹5,060.00 |
| 2,500+ | ₹9.59 | ₹23,975.00 |
| 5,000+ | ₹9.23 | ₹46,150.00 |
5 × ₹16.99
₹84.95
excl. GST
₹100.24 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
OP07CDR
₹84.95 for 5 + GST
Specifications
- Number of Channels
- 1
- Vos - Input Offset Voltage
- 60uV
- Slew Rate
- 0.3V/us
- Input Offset Current(Ios)
- 800pA
- Operating Temperature
- 0℃~+70℃
- Common Mode Rejection Ratio(CMRR)
- 120dB
- Ib - Input Bias Current
- 1.8nA
- Input Offset Voltage Drift(Vos TC)
- 500nV/℃
- Gain Bandwidth Product
- 400kHz
- Features
- Built-in compensation
- Input Voltage Noise Density
- 10.5nV/√Hz@10Hz
- Dual Supply
- -18V~-3V;3V~18V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.196 g
Overview
These devices offer low offset and long - term stability by means of a low - noise, chopperless, bipolar - input transistor amplifier circuit. For most applications, external components are not required for offset nulling and frequency compensation. The true differential input, with a wide input - voltage range and outstanding common - mode rejection, provides maximum flexibility and performance in high - noise environments and in noninverting applications. Low bias currents and extremely high input impedances are maintained over the entire temperature range. The OP07 devices are unsurpassed for low - noise, high - accuracy amplification of very - low - level signals. These devices are characterized for operation from 0℃ to 70℃.
Key features
- Low Noise
- No External Components Required
- Replace Chopper Amplifiers at a Lower Cost
- Wide Input - Voltage Range: 0 to ±14 V Typ
- Wide Supply - Voltage Range: ±3 V to ±18 V
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | OP07CD#C354130TI · SOIC-8 | TI | SOIC-8 | 2,005 | ₹40.33 · 2,005 in stock | View |
 | OP07CSZ-REEL7#C143866ADI · SOIC-8 | ADI | SOIC-8 | 1,570 | ₹286.81 · 1,570 in stock | View |
 | OP07CSZ-REEL#C21378ADI · SOIC-8 | ADI | SOIC-8 | 12,925 | ₹245.22 · 12,925 in stock | View |
 | OP07CSZ#C1346196ADI · SOIC-8 | ADI | SOIC-8 | 181 | ₹296.39 · 181 in stock | View |
 | OP07D#C510565HTC · SOP-8 | HTC | SOP-8 | 460 | ₹44.08 · 460 in stock | View |
