OPA197IDBVR

65mA 1 100uV 20V/us 140dB 5pA 1mA 10MHz Rail-to-Rail Input, Rail-to-Rail Output SOT-23-5 Instrumentation, Op Amps, Buffer Amps RoHS

SOT-23-5ROHS3 CompliantActive

Precision, Rail-to-Rail Input/Output, Low Offset Voltage, Operational Amplifiers

Manufacturer: TI
Manufacturer part #: OPA197IDBVR
Store part #: C221351
Package / case: SOT-23-5
Category: Instrumentation, Op Amps, Buffer Amps
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

83,266 in stock

#C221351

Stock & price checked 3 days ago

Quantity	Unit price	Pack price
1+	₹116.60	₹116.60
10+	₹101.59	₹1,015.90
30+	₹87.24	₹2,617.20
100+	₹76.79	₹7,679.00
500+	₹72.45	₹36,225.00
1,000+	₹70.26	₹70,260.00

Quantity (min 1)

1 × ₹116.60

₹116.60

excl. GST

₹137.59 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 3,000 per reel

OPA197IDBVR

₹116.60 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Output Current: 65mA
Number of Channels: 1
Vos - Input Offset Voltage: 100uV
Slew Rate: 20V/us
Input Offset Current(Ios): 20pA
Operating Temperature: -40℃~+125℃
Common Mode Rejection Ratio(CMRR): 140dB
Ib - Input Bias Current: 5pA
Input Offset Voltage Drift(Vos TC): 2.5uV/℃
Quiescent Current: 1mA
Gain Bandwidth Product: 10MHz
Features: EMI filtering/RF suppression
Input Voltage Noise Density: 5.5nV/√Hz@1kHz
Dual Supply: -18V~-2.25V;2.25V~18V
Rail to Rail: Rail-to-Rail Input, Rail-to-Rail Output
Single Supply: 4.5V~36V

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
Moisture sensitivity: MSL 2 (1 year)
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.026 g

Overview

The OPAx197 family (OPA197, OPA2197, and OPA4197) is a new generation of 36-V operational amplifiers. These devices offer outstanding dc precision and ac performance, including rail-to-rail input/output, low offset (±25 µv, typical), low offset drift (±0.25 µv/°C, typ), and 10-MHz bandwidth. Unique features such as differential input-voltage range to the supply rail, high output current (±65 mA), high capacitive load drive of up to 1 nF, and high slew rate (20 V/µs) make the OPA197 a robust, highperformance operational amplifier for high-voltage, industrial applications. The OPA197 family of op amps is available in standard packages and is specified from -40°C to +125°C.

Applications

Multiplexed Data-Acquisition Systems
Test and Measurement Equipment
High-Resolution ADC Driver Amplifiers
SAR ADC Reference Buffers
Programmable Logic Controllers
High-Side and Low-Side Current Sensing
High Precision Comparators

Key features

Low Offset Voltage: ±100 µv (Maximum)
Low Offset Voltage Drift: ±2.5 µv/°C (Maximum)
Low Noise: 5.5 nV/√Hz at 1 kHz
High Common-Mode Rejection: 120 dB (Minimum)
Low Bias Current: ±5 pA (Typical)
Rail-to-Rail Input and Output
Wide Bandwidth: 10-MHz GBW
High Slew Rate: 20 V/µs
Low Quiescent Current: 1 mA per Amplifier (Typical)
Wide Supply: ±2.25 V to ±18 V, +4.5 V to +36 V
EMI- and RFI-Filtered Inputs
Differential Input Voltage Range to Supply Rail
High Capacitive Load Drive Capability: 1 nF
Industry Standard Packages:
Single in SOIC-8, SOT-5, and VSSOP-8
Dual in SOIC-8 and VSSOP-8
Quad in SOIC-14 and TSSOP-14
