TECH PUBLICDatasheet (PDF)
RB400D
40V 1 Independent 500mV@500mA 500mA SOT-23 Single Diodes
SOT-23RoHSActive
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- RB400D
- Store part #
- C53340907
- Package / case
- SOT-23
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,560 in stock
#C53340907
Stock & price checked 11 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹3.41 | ₹68.20 |
| 200+ | ₹2.66 | ₹532.00 |
| 600+ | ₹2.24 | ₹1,344.00 |
| 3,000+ | ₹1.98 | ₹5,940.00 |
| 9,000+ | ₹1.76 | ₹15,840.00 |
| 21,000+ | ₹1.64 | ₹34,440.00 |
20 × ₹3.41
₹68.20
excl. GST
₹80.48 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
RB400D
₹68.20 for 20 + GST
Specifications
- Voltage - DC Reverse (Vr) (Max)
- 40V
- Diode Configuration
- 1 Independent
- Voltage - Forward(Vf@If)
- 500mV@500mA
- Reverse Leakage Current (Ir)
- 20uA@40V
- Non-Repetitive Peak Forward Surge Current
- 5.5A
- Current - Rectified
- 500mA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 0.033 g
Overview
Applications
- Surface mount Schottky barrier rectifier
- Buck and boost DC-DC converters
- Low voltage high frequency switching power supplies
- Low voltage high frequency inverter circuits
- Low voltage continuous circuits and protection circuits
Key features
- Low forward voltage drop
- Guard ring structure for transient protection
- Fast switching
- Low leakage current
- RoHS compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | BAT400D#C53340703TECH PUBLIC · SOT-23 | TECH PUBLIC | SOT-23 | 2,940 | ₹3.41 · 2,940 in stock | View |
 | SB05-03C(TP)#C53340840TECH PUBLIC · SOT-23 | TECH PUBLIC | SOT-23 | 2,900 | ₹3.41 · 2,900 in stock | View |
 | RB411D#C53340908TECH PUBLIC · SOT-23 | TECH PUBLIC | SOT-23 | 2,980 | ₹3.41 · 2,980 in stock | View |
 | TPB1000S3#C7472891TECH PUBLIC · SOT-23 | TECH PUBLIC | SOT-23 | 205 | ₹9.41 · 205 in stock | View |
 | BAT750TA(TP)#C53340704TECH PUBLIC · SOT-23 | TECH PUBLIC | SOT-23 | 3,260 | ₹5.13 · 3,260 in stock | View |
