VISHAYDatasheet (PDF)
S1K-E3/5AT
Diode 1 Independent 800V 1A Surface Mount DO-214AC(SMA)
DO-214AC(SMA)ROHS3 CompliantActive
DIODE STANDARD 800V 1A DO-214AC(SMA)
- Manufacturer
- VISHAY
- Manufacturer part #
- S1K-E3/5AT
- Store part #
- C5358730
- Package / case
- DO-214AC(SMA)
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,210 in stock
#C5358730
Stock & price checked 13 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹7.77 | ₹77.70 |
| 100+ | ₹6.13 | ₹613.00 |
| 300+ | ₹5.31 | ₹1,593.00 |
| 1,000+ | ₹4.68 | ₹4,680.00 |
| 7,500+ | ₹4.19 | ₹31,425.00 |
| 15,000+ | ₹3.96 | ₹59,400.00 |
10 × ₹7.77
₹77.70
excl. GST
₹91.69 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 7,500 per reel
S1K-E3/5AT
₹77.70 for 10 + GST
Specifications
- Operating Junction Temperature Range
- -55℃~+150℃
- Diode Configuration
- 1 Independent
- Voltage - DC Reverse (Vr) (Max)
- 800V
- Voltage - Forward(Vf@If)
- 1.1V@1A
- Reverse Leakage Current (Ir)
- 5uA
- Current - Rectified
- 1A
- Non-Repetitive Peak Forward Surge Current
- 30A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 7,500 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.115 g
Overview
Applications
- For use in general purpose rectification of power supplies, inverters, converters and freewheeling diodes for consumer, automotive, and telecommunication.
Key features
- Low profile package Available
- Ideal for automated placement
- Glass passivated pellet chip junction
- Low forward voltage drop RoHS COMPLIANT
- Low leakage current HALOGEN
- High forward surge capability FREE
- Meets MSL level 1, per J-STD-020, LF maximum peak of 260 ℃
- AEC-Q101 qualified available - Automotive ordering code: base P/NHE3 or P/NHM3
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | S1M-M3/61T#C17269411VISHAY · DO-214AC(SMA) | VISHAY | DO-214AC(SMA) | 1,575 | ₹24.37 · 1,575 in stock | View |
 | GN1M#C174024Suzhou Good-Ark Elec · SMA(DO-214AC) | Suzhou Good-Ark Elec | SMA(DO-214AC) | 8,860 | ₹5.66 · 8,860 in stock | View |
 | H2000#C19273128YFW · SMA | YFW | SMA | 5,000 | ₹6.03 · 5,000 in stock | View |
 | EM520#C20606481YFW · SMA | YFW | SMA | 3,540 | ₹5.48 · 3,540 in stock | View |
 | M7#C20622486Wild Goose · SMA(DO-214AC) | Wild Goose | SMA(DO-214AC) | 2,600 | ₹0.8864 · 2,600 in stock | View |
