VISHAYDatasheet (PDF)
S2J-E3/52T
Diode 600V 1.5A Surface Mount SMB(DO-214AA)
SMB(DO-214AA)ROHS3 CompliantActive
DIODE STANDARD 600V 1.5A SMB(DO-214AA)
- Manufacturer
- VISHAY
- Manufacturer part #
- S2J-E3/52T
- Store part #
- C435920
- Package / case
- SMB(DO-214AA)
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
340 in stock
#C435920
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹20.40 | ₹102.00 |
| 50+ | ₹16.14 | ₹807.00 |
| 150+ | ₹14.31 | ₹2,146.50 |
| 750+ | ₹10.35 | ₹7,762.50 |
| 2,250+ | ₹9.33 | ₹20,992.50 |
| 5,250+ | ₹8.72 | ₹45,780.00 |
5 × ₹20.40
₹102.00
excl. GST
₹120.36 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 750 per reel
S2J-E3/52T
₹102.00 for 5 + GST
Specifications
- Operating Junction Temperature Range
- -55℃~+150℃
- Voltage - DC Reverse (Vr) (Max)
- 600V
- Diode Configuration
- 1 Independent
- Voltage - Forward(Vf@If)
- 1.15V@1.5A
- Reverse Leakage Current (Ir)
- 1uA@600V
- Non-Repetitive Peak Forward Surge Current
- 50A
- Current - Rectified
- 1.5A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 750 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.204 g
Overview
Applications
- For use in general purpose rectification of power supplies, inverters, converters and freewheeling diodes for consumer, automotive and telecommunication.
Key features
- Low profile package
- Ideal for automated placement
- Glass passivated chip junction
- Low forward voltage drop RoHS
- Low leakage current COMPLIANT
- High forward surge capability
- Meets MSL level 1, per J-STD-020, LF maximum peak of 260℃
- AEC-Q101 qualified
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | S2JHE3_A/H#C17383984VISHAY · DO-214AA(SMB) | VISHAY | DO-214AA(SMB) | 270 | ₹18.22 · 270 in stock | View |
 | S2JHE3_A/I#C241923VISHAY · DO-214AA(SMB) | VISHAY | DO-214AA(SMB) | 840 | ₹10.49 · 840 in stock | View |
 | S2K-E3/52T#C3009013VISHAY · DO-214AA(SMB) | VISHAY | DO-214AA(SMB) | 95 | ₹24.98 · 95 in stock | View |
 | S2J#C894240onsemi · DO-214AA(SMB) | onsemi | DO-214AA(SMB) | 30 | ₹14.65 · 30 in stock | View |
 | S2M-E3/52T#C968639VISHAY · DO-214AA | VISHAY | DO-214AA | 915 | ₹21.96 · 915 in stock | View |
