DIODESDatasheet (PDF)
SBR1U200P1Q-7
25ns 200V 1 Independent 820mV@1A 1A PowerDI-123 Single Diodes RoHS
PowerDI-123ROHS3 CompliantActive
Voltage： 200V Current： 1A
- Manufacturer
- DIODES
- Manufacturer part #
- SBR1U200P1Q-7
- Store part #
- C460951
- Package / case
- PowerDI-123
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
841 in stock
#C460951
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹67.43 | ₹67.43 |
| 10+ | ₹54.43 | ₹544.30 |
| 30+ | ₹49.00 | ₹1,470.00 |
| 100+ | ₹42.07 | ₹4,207.00 |
| 500+ | ₹39.03 | ₹19,515.00 |
| 1,000+ | ₹37.08 | ₹37,080.00 |
1 × ₹67.43
₹67.43
excl. GST
₹79.57 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SBR1U200P1Q-7
₹67.43 for 1 + GST
Specifications
- Reverse Recovery Time (trr)
- 25ns
- Operating Junction Temperature Range
- -65℃~+175℃
- Voltage - DC Reverse (Vr) (Max)
- 200V
- Diode Configuration
- 1 Independent
- Voltage - Forward(Vf@If)
- 820mV@1A
- Reverse Leakage Current (Ir)
- 50uA@200V
- Non-Repetitive Peak Forward Surge Current
- 40A
- Current - Rectified
- 1A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.026 g
Overview
The SBR1U200P1Q is a single rectifier in the PowerDI123 package, offering excellent high- temperature stability and low- forward voltage.
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SBR1U200P1-7#C86903DIODES · PowerDI-123 | DIODES | PowerDI-123 | 5,525 | ₹41.30 · 5,525 in stock | View |
 | SBR1U400P1-7#C145498DIODES · PowerDI-123 | DIODES | PowerDI-123 | 4,815 | ₹24.04 · 4,815 in stock | View |
