DIODESDatasheet (PDF)
SBR2A30P1-7
30V 400mV@2A 2A PowerDI-123 Single Diodes RoHS
PowerDI-123ROHS3 CompliantActive
Voltage： 30V Current： 2A
- Manufacturer
- DIODES
- Manufacturer part #
- SBR2A30P1-7
- Store part #
- C444993
- Package / case
- PowerDI-123
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
365 in stock
#C444993
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹25.36 | ₹126.80 |
| 50+ | ₹21.23 | ₹1,061.50 |
| 150+ | ₹19.16 | ₹2,874.00 |
| 500+ | ₹17.61 | ₹8,805.00 |
| 3,000+ | ₹16.11 | ₹48,330.00 |
| 6,000+ | ₹15.49 | ₹92,940.00 |
5 × ₹25.36
₹126.80
excl. GST
₹149.62 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SBR2A30P1-7
₹126.80 for 5 + GST
Specifications
- Operating Junction Temperature Range
- -65℃~+150℃
- Voltage - DC Reverse (Vr) (Max)
- 30V
- Voltage - Forward(Vf@If)
- 400mV@2A
- Reverse Leakage Current (Ir)
- 55uA@30V
- Non-Repetitive Peak Forward Surge Current
- 75A
- Current - Rectified
- 2A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.027 g
Overview
Key features
- Low Forward Voltage Drop
- Low Leakage Current
- Superior Reverse Avalanche Capability
- Excellent High Temperature Stability
- Patented Interlocking Clip Design for High Surge Current Capacity
- Patented Super Barrier Rectifier Technology
- Soft, Fast Switching Capability
- 150℃ Operating Junction Temperature
- ±16 KV ESD Protection (HBM, 3B)
- ±25 KV ESD Protection (IEC61000-4-2 Level 4, Air Discharge)
- Lead Free Finish, RoHS Compliant
- “Green” Molding Compound (No Br, Sb) Qualified to AEC-Q101 Standards for High Reliability
