VISHAYDatasheet (PDF)
SE30AFD-M3/6A
200V 1 Independent 1.1V@3A 3A DO-221AC Single Diodes RoHS
DO-221ACROHS3 CompliantActive
- Manufacturer
- VISHAY
- Manufacturer part #
- SE30AFD-M3/6A
- Store part #
- C17220674
- Package / case
- DO-221AC
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
40 in stock
#C17220674
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹36.38 | ₹181.90 |
| 50+ | ₹35.79 | ₹1,789.50 |
| 150+ | ₹35.39 | ₹5,308.50 |
| 500+ | ₹34.99 | ₹17,495.00 |
5 × ₹36.38
₹181.90
excl. GST
₹214.64 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,500 per reel
SE30AFD-M3/6A
₹181.90 for 5 + GST
Specifications
- Operating Junction Temperature Range
- -55℃~+175℃
- Voltage - DC Reverse (Vr) (Max)
- 200V
- Diode Configuration
- 1 Independent
- Voltage - Forward(Vf@If)
- 1.1V@3A
- Reverse Leakage Current (Ir)
- 10uA
- Non-Repetitive Peak Forward Surge Current
- 40A
- Current - Rectified
- 3A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.138 g
Overview
Applications
- General purpose
- Power line polarity protection
- Consumer applications
- Automotive applications
Key features
- Very low profile - typical height of 0.95 mm Available
- Ideal for automated placement
- Oxide planar chip junction
- Low forward voltage drop, low leakage current RoHS COMPLIANT
- ESD capability HALOGEN
- Meets MSL level 1, per J-STD-020, FREE LF maximum peak of 260 ℃
- AEC-Q101 qualified
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SE30AFG-M3/6A#C17431197VISHAY · DO-221AC | VISHAY | DO-221AC | 60 | ₹36.89 · 60 in stock | View |
 | SE30AFDHM3/6A#C3009008VISHAY · DO-221AC(SMA-FL) | VISHAY | DO-221AC(SMA-FL) | 3,245 | ₹29.93 · 3,245 in stock | View |
 | S3AFGHM3/I#C20036250VISHAY · DO-221AC(SLIMSMA) | VISHAY | DO-221AC(SLIMSMA) | 243 | ₹129.14 · 243 in stock | View |
| SE8D30GHM3/H#C17182789VISHAY · DO-221AC(SMA) | VISHAY | DO-221AC(SMA) | On request | ₹52.36 · 0 in stock | View | |
| SE30AFGHM3/6B#C17216429VISHAY · DO-221AC | VISHAY | DO-221AC | On request | ₹41.33 · 0 in stock | View | |
