SIT65HVD231DR
3V~3.6V CAN Transceiver 1Mbps SOP-8 Drivers, Receivers, Transceivers RoHS
SOP-8ROHS CompliantActive
SIT65HVD231 3.3V Power Supply, High ESD Protection, Ultra-low Sleep Power Consumption, 1Mbps High-speed CAN Bus Transceiver
- Manufacturer
- SIT
- Manufacturer part #
- SIT65HVD231DR
- Store part #
- C841402
- Package / case
- SOP-8
- Category
- Drivers, Receivers, Transceivers
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,029 in stock
#C841402
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹71.71 | ₹71.71 |
| 10+ | ₹57.59 | ₹575.90 |
| 30+ | ₹51.72 | ₹1,551.60 |
| 100+ | ₹44.33 | ₹4,433.00 |
| 500+ | ₹38.68 | ₹19,340.00 |
| 1,000+ | ₹36.73 | ₹36,730.00 |
1 × ₹71.71
₹71.71
excl. GST
₹84.62 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
SIT65HVD231DR
₹71.71 for 1 + GST
Specifications
- Voltage - Supply
- 3V~3.6V
- Type
- CAN Transceiver
- number of channels
- 1
- Data Rate
- 1Mbps
- Operating Temperature
- -40℃~+125℃
- Features
- Low-power mode;Wake-up function;Short-Circuit Protection;Thermal shutdown protection;ESD protection;Hot-swap protection
- Supply Current
- 70mA
- Quiescent Supply Current
- 1uA
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.361 g
Overview
The SIT65HVD231 is the interface between the Controller Area Network (CAN) protocol controller and the physical bus. It is designed for use with the 3.3V μPs, MCUs and DSPs with CAN controllers, or with equivalent protocol controller devices. It is used in industrial automation, control, sensors and drive systems, motor and robotic control, building and climate control (HVAC), telecom and basestation control and status. The devices are intended for use in applications employing the CAN serial communication physical layer in accordance with the ISO 11898 standard.
Applications
- industrial automation
- control
- sensors and drive systems
- motor and robotic control
- building and climate control (HVAC)
- telecom and basestation control and status
Key features
- Operates with a single 3.3V supply
- Compatible with ISO 11898 - 2 standard
- Bus pin ESD protection exceeds ±16 kV HBM
- At least 120 nodes can be connected
- Adjustable drive conversion time can improve radiation performance
- Ultra - low current sleep mode: 40 nA (typical value)
- Designed for data rates up to 1 Mbps
- Thermal Shutdown Protection
- Open circuit fail - safe design
- Glitch free power up and power down protection for hot plugging applications
- Provide Green and Environmentally Friendly Lead - free package
