HXY MOSFETDatasheet (PDF)
SKL36-HXY
1 Independent 60V 700mV@3A 3A SOD-123FL Single Diodes
SOD-123FLRoHSActive
- Manufacturer
- HXY MOSFET
- Manufacturer part #
- SKL36-HXY
- Store part #
- C52754510
- Package / case
- SOD-123FL
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
180 in stock
#C52754510
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹21.75 | ₹108.75 |
| 50+ | ₹17.42 | ₹871.00 |
| 150+ | ₹15.57 | ₹2,335.50 |
| 500+ | ₹13.26 | ₹6,630.00 |
| 3,000+ | ₹12.22 | ₹36,660.00 |
| 6,000+ | ₹11.60 | ₹69,600.00 |
5 × ₹21.75
₹108.75
excl. GST
₹128.32 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SKL36-HXY
₹108.75 for 5 + GST
Specifications
- Diode Configuration
- 1 Independent
- Operating Junction Temperature Range
- -65℃~+150℃
- Voltage - DC Reverse (Vr) (Max)
- 60V
- Voltage - Forward(Vf@If)
- 700mV@3A
- Reverse Leakage Current (Ir)
- 100uA
- Current - Rectified
- 3A
- Non-Repetitive Peak Forward Surge Current
- 80A
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.034 g
Overview
Key features
- Surface mount application
- Easy pick and place
- Built-in strain relief
- Low forward voltage drop
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | NRVBSS36FA-HXY#C52754508HXY MOSFET · SOD-123FL | HXY MOSFET | SOD-123FL | 175 | ₹54.56 · 175 in stock | View |
 | RBR3MM60ATFTR-HXY#C52754509HXY MOSFET · SOD-123FL | HXY MOSFET | SOD-123FL | 115 | ₹20.14 · 115 in stock | View |
 | SS36FA-HXY#C52754511HXY MOSFET · SOD-123FL | HXY MOSFET | SOD-123FL | 185 | ₹36.98 · 185 in stock | View |
 | DSS310#C20616306HXY MOSFET · SOD-123FL | HXY MOSFET | SOD-123FL | 50 | ₹5.86 · 50 in stock | View |
 | NRVBS310FA-HXY#C52754497HXY MOSFET · SOD-123FL | HXY MOSFET | SOD-123FL | 121 | ₹67.21 · 121 in stock | View |
