TECH PUBLIC

SN74AUP1T17DCKR-TP

SOT-353 Translators, Level Shifters RoHS

SOT-353ROHS CompliantActive

Manufacturer: TECH PUBLIC
Manufacturer part #: SN74AUP1T17DCKR-TP
Store part #: C51939607
Package / case: SOT-353
Category: Translators, Level Shifters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,780 in stock

#C51939607

Stock & price checked 3 days ago

Quantity	Unit price	Pack price
5+	₹13.15	₹65.75
50+	₹10.31	₹515.50
150+	₹8.89	₹1,333.50
500+	₹7.83	₹3,915.00
3,000+	₹6.99	₹20,970.00
6,000+	₹6.56	₹39,360.00

Quantity (min 5, multiples of 5)

5 × ₹13.15

₹65.75

excl. GST

₹77.58 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 3,000 per reel

SN74AUP1T17DCKR-TP

₹65.75 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 1 g

Overview

This device provides a single-buffer function, ensuring ultra-low static and dynamic power consumption across the entire VCC range of 2.3V to 3.6V. Designed for logic-level translation applications, its input switching levels accept 1.8V low-voltage CMOS signals while operating from a single 2.5V or 3.3V supply voltage. The wide supply voltage range ensures proper operation as the battery voltage drops from 3.6V to 2.3V. Schmitt-trigger inputs provide tolerance to slower input rise and fall times across the entire VCC range.

Applications

AV receiver
Embedded PC
Solid-state drive

Key features

Wide supply voltage range: 2.3V to 3.6V
Inputs accept voltages up to 3.6V
I<sub>OFF</sub> supports partial power-down mode
Low quiescent current; I<sub>CC</sub> = 1.5μA (maximum)
ESD protection exceeds JESD 22: 2000-V HBM (A114-A), 200-V MM (A115-A), 1000-V CDM (C101)
