KUUDatasheet (PDF)
SS10100
1 Independent 100V 670mV@10A 10A TO-277B Single Diodes
TO-277BRoHSActive
DIODE SCHOTTKY 100V TO-277B
- Manufacturer
- KUU
- Manufacturer part #
- SS10100
- Store part #
- C49270367
- Package / case
- TO-277B
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,845 in stock
#C49270367
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹24.41 | ₹122.05 |
| 50+ | ₹19.17 | ₹958.50 |
| 150+ | ₹16.92 | ₹2,538.00 |
| 500+ | ₹14.12 | ₹7,060.00 |
| 2,500+ | ₹12.87 | ₹32,175.00 |
| 5,000+ | ₹12.12 | ₹60,600.00 |
5 × ₹24.41
₹122.05
excl. GST
₹144.02 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
SS10100
₹122.05 for 5 + GST
Specifications
- Diode Configuration
- 1 Independent
- Voltage - DC Reverse (Vr) (Max)
- 100V
- Operating Junction Temperature Range
- -55℃~+150℃
- Voltage - Forward(Vf@If)
- 670mV@10A
- Reverse Leakage Current (Ir)
- 100uA@100V
- Current - Rectified
- 10A
- Non-Repetitive Peak Forward Surge Current
- 220A
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.131 g
Overview
The device contains a high-efficiency, low-power general-purpose Schottky rectifier. Its clip-bonded lead structure provides excellent thermal performance and low resistance.
Applications
- Low-voltage high-frequency inverters
- Freewheeling diodes
- DC/DC converters
- Polarity protection
Key features
- Low-profile package
- VRRM 100V, IF(AV) 10A
- Suitable for automated placement
- Ultra-fast reverse recovery time
- Low power consumption, high efficiency
- Low forward voltage drop
- High forward surge current capability
- High-temperature soldering capability: 260℃/10s at terminals
