VISHAYDatasheet (PDF)
SS23-E3/52T
Diode 1 Independent 30V 2A Surface Mount DO-214AA(SMB)
DO-214AA(SMB)ROHS3 CompliantActive
DIODE SCHOTTKY 30V DO-214AA(SMB)
- Manufacturer
- VISHAY
- Manufacturer part #
- SS23-E3/52T
- Store part #
- C3759965
- Package / case
- DO-214AA(SMB)
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
565 in stock
#C3759965
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹38.79 | ₹193.95 |
| 50+ | ₹32.23 | ₹1,611.50 |
| 150+ | ₹29.41 | ₹4,411.50 |
| 750+ | ₹24.20 | ₹18,150.00 |
| 2,250+ | ₹22.64 | ₹50,940.00 |
| 5,250+ | ₹21.70 | ₹1,13,925.00 |
5 × ₹38.79
₹193.95
excl. GST
₹228.86 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 750 per reel
SS23-E3/52T
₹193.95 for 5 + GST
Specifications
- Diode Configuration
- 1 Independent
- Operating Junction Temperature Range
- -65℃~+150℃
- Voltage - DC Reverse (Vr) (Max)
- 30V
- Voltage - Forward(Vf@If)
- 500mV@2A
- Reverse Leakage Current (Ir)
- 400uA@30V
- Non-Repetitive Peak Forward Surge Current
- 75A
- Current - Rectified
- 2A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 750 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.233 g
Overview
Applications
- Low voltage high frequency inverters
- Freewheeling
- DC/DC converters
- Polarity protection applications
Key features
- Low profile package
- Ideal for automated placement
- Guardring for overvoltage protection
- Low power losses, high efficiency
- Low forward voltage drop
- High surge capability
- Meets MSL level 1, per J-STD-020, LF maximum peak of 260℃
- AEC-Q101 qualified available
- Automotive ordering code: base P/NHE3 or P/NHM3
- Material categorization: for definitions of compliance please see doc?99912
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SS24-E3/52T#C163209VISHAY · DO-214AA | VISHAY | DO-214AA | 9,900 | ₹19.13 · 9,900 in stock | View |
 | SS24-E3/5BT#C467994VISHAY · SMB(DO-214AA) | VISHAY | SMB(DO-214AA) | 5,240 | ₹22.04 · 5,240 in stock | View |
 | SS24HE3_A/H#C5158076VISHAY · DO-214AA(SMB) | VISHAY | DO-214AA(SMB) | 263 | ₹69.33 · 263 in stock | View |
 | SS24T3G#C85393onsemi · SMB(DO-214AA) | onsemi | SMB(DO-214AA) | 1,870 | ₹30.10 · 1,870 in stock | View |
 | SS24#C266555BORN · SMB(DO-214AA) | BORN | SMB(DO-214AA) | 10,230 | ₹5.36 · 10,230 in stock | View |
