TECH PUBLICDatasheet (PDF)
SS24FL
40V 1 Independent 550mV@2A 2A SOD-123FL Single Diodes
SOD-123FLRoHSActive
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- SS24FL
- Store part #
- C53340919
- Package / case
- SOD-123FL
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
180 in stock
#C53340919
Stock & price checked 11 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹6.95 | ₹69.50 |
| 100+ | ₹5.46 | ₹546.00 |
| 300+ | ₹4.72 | ₹1,416.00 |
| 3,000+ | ₹4.17 | ₹12,510.00 |
| 6,000+ | ₹3.72 | ₹22,320.00 |
| 9,000+ | ₹3.51 | ₹31,590.00 |
10 × ₹6.95
₹69.50
excl. GST
₹82.01 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SS24FL
₹69.50 for 10 + GST
Specifications
- Voltage - DC Reverse (Vr) (Max)
- 40V
- Operating Junction Temperature Range
- -55℃~+150℃
- Diode Configuration
- 1 Independent
- Voltage - Forward(Vf@If)
- 550mV@2A
- Reverse Leakage Current (Ir)
- 100uA@40V
- Non-Repetitive Peak Forward Surge Current
- 50A
- Current - Rectified
- 2A
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.039 g
Overview
Applications
- Low-voltage rectification
- Reverse polarity protection
- Low-power applications
Key features
- Low power dissipation, high efficiency
- High surge current capability
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | RB060MM-40TR(TP)#C53340832TECH PUBLIC · SOD-123FL | TECH PUBLIC | SOD-123FL | 2,470 | ₹6.91 · 2,470 in stock | View |
 | MBR230S1F#C41408002TECH PUBLIC · SOD-123FL | TECH PUBLIC | SOD-123FL | 1,710 | ₹9.06 · 1,710 in stock | View |
 | PMEG3020ER-TP#C48886790TECH PUBLIC · SOD-123FL | TECH PUBLIC | SOD-123FL | 2,850 | ₹7.79 · 2,850 in stock | View |
 | PMEG40T20ERX(TP)#C53340828TECH PUBLIC · SOD-123FL | TECH PUBLIC | SOD-123FL | 1,870 | ₹6.91 · 1,870 in stock | View |
 | RB068MM-40TR(TP)#C53340833TECH PUBLIC · SOD-123FL | TECH PUBLIC | SOD-123FL | 2,960 | ₹6.91 · 2,960 in stock | View |
