VISHAYDatasheet (PDF)
SS2P6-M3/84A
Diode 1 Independent 60V 2A Surface Mount DO-220AA
DO-220AAROHS3 CompliantActive
DIODE SCHOTTKY 60V DO-220AA
- Manufacturer
- VISHAY
- Manufacturer part #
- SS2P6-M3/84A
- Store part #
- C5137032
- Package / case
- DO-220AA
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
50 in stock
#C5137032
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹26.91 | ₹134.55 |
| 50+ | ₹26.35 | ₹1,317.50 |
| 150+ | ₹25.98 | ₹3,897.00 |
| 500+ | ₹25.61 | ₹12,805.00 |
5 × ₹26.91
₹134.55
excl. GST
₹158.77 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SS2P6-M3/84A
₹134.55 for 5 + GST
Specifications
- Diode Configuration
- 1 Independent
- Operating Junction Temperature Range
- -55℃~+150℃
- Voltage - DC Reverse (Vr) (Max)
- 60V
- Voltage - Forward(Vf@If)
- 700mV@2A
- Reverse Leakage Current (Ir)
- 100uA@60V
- Non-Repetitive Peak Forward Surge Current
- 50A
- Current - Rectified
- 2A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.062 g
Overview
Applications
- For use in low voltage high frequency inverters, freewheeling, DC/DC converters, and polarity protection applications.
Key features
- Very low profile - typical height of 1.1mm
- Ideal for automated placement
- Low forward voltage drop, low power losses
- High efficiency
- Low thermal resistance
- Meets MSL level 1, per J-STD-020, LF maximum peak of 260℃
- AEC-Q101 qualified available
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SS2P6HM3/84A#C2981060VISHAY · DO-220AA | VISHAY | DO-220AA | 860 | ₹48.58 · 860 in stock | View |
 | SS3P6HM3/84A#C968544VISHAY · DO-220AA | VISHAY | DO-220AA | 290 | ₹20.93 · 290 in stock | View |
 | SS3P6HM3/85A#C2981051VISHAY · DO-220AA(SMP) | VISHAY | DO-220AA(SMP) | 2,100 | ₹15.24 · 2,100 in stock | View |
 | SS2PH10-M3/84A#C77393VISHAY · DO-220AA | VISHAY | DO-220AA | 3,480 | ₹28.55 · 3,480 in stock | View |
 | V2P22L-M3/H#C3757426VISHAY · DO-220AA(SMP) | VISHAY | DO-220AA(SMP) | 45 | ₹29.40 · 45 in stock | View |
