STDatasheet (PDF)
ST732M36R
3.6V Positive Fixed SOT-23-5L Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
SOT-23-5LROHS3 CompliantActive
300 mA, 28V low-dropout regulator, 6 uA quiescent current
- Manufacturer
- ST
- Manufacturer part #
- ST732M36R
- Store part #
- C3744211
- Package / case
- SOT-23-5L
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
50 in stock
#C3744211
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹163.66 | ₹163.66 |
| 10+ | ₹136.73 | ₹1,367.30 |
| 30+ | ₹121.87 | ₹3,656.10 |
| 100+ | ₹100.77 | ₹10,077.00 |
| 500+ | ₹93.25 | ₹46,625.00 |
| 1,000+ | ₹90.02 | ₹90,020.00 |
1 × ₹163.66
₹163.66
excl. GST
₹193.12 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
ST732M36R
₹163.66 for 1 + GST
Specifications
- Output Voltage
- 3.6V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+125℃@(Ta)
- Supply Current (Iq)
- 200uA
- Output Configuration
- Positive
- Output Current
- 300mA
- Operating Voltage
- 28V
- Features
- Over Current Protection;Short Circuit Protection;Thermal shutdown
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.039 g
Overview
The ST732 is 300 mA LDO regulator, designed to be used in several medium voltage applications. Ultra-low quiescent current of 5 μA makes it suitable for applications permanently connected to power supply/battery. This feature is also useful when electronic modules remain permanently turned on. The ST732 embeds protection functions, such as: current limit, short-circuit and thermal shutdown. The extended input voltage range, very low drop voltage and low quiescent current features make it suitable also for low power after-market automotive and consumer applications.
Applications
- Post regulation
- Electronic meters
- Smoke detectors / alarms
- Portable equipment
- Industrial applications
Key features
- Wide input voltage range: 2.5 V to 28 V
- Ultra-low quiescent current: typ. 5 μA at no-load, 10 μA max. across full temperature range
- Output voltage accuracy: ± 2%
- Output current up to 300 mA
- Fixed output voltage versions, starting from 1.2 V with 100 mV step
- Stable with low ESR capacitors (0.47 μF min.)
- Thermal shutdown protection
- Current limit protection
- -40 °C to +125 °C operating temperature range
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | ST730M36R#C5268053ST · SOT-23-5L | ST | SOT-23-5L | 4 | ₹134.18 · 4 in stock | View |
 | MD85E36QC3#C920478Mingda Microelectronics · SOT-23-5L | Mingda Microelectronics | SOT-23-5L | 2,915 | ₹17.27 · 2,915 in stock | View |
 | MD8436#C2978594Mingda Microelectronics · SOT-23-5L | Mingda Microelectronics | SOT-23-5L | 40 | ₹19.78 · 40 in stock | View |
 | SK6513SS5E-36#C5120325Suntek · SOT-23-5 | Suntek | SOT-23-5 | 2,121 | ₹24.30 · 2,121 in stock | View |
 | XC6204B362MR#C18212679TECH PUBLIC · SOT-23-5 | TECH PUBLIC | SOT-23-5 | 2,200 | ₹13.49 · 2,200 in stock | View |
