STM1001RWX6F
30ms Active Low 1V~5.5V 1 SOT-23 Supervisors RoHS
SOT-23ROHS3 CompliantActive
STM1001 Microprocessor Reset Circuit
- Manufacturer
- ST
- Manufacturer part #
- STM1001RWX6F
- Store part #
- C115151
- Package / case
- SOT-23
- Category
- Supervisors
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
574 in stock
#C115151
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹71.68 | ₹71.68 |
| 10+ | ₹56.78 | ₹567.80 |
| 30+ | ₹50.53 | ₹1,515.90 |
| 100+ | ₹42.75 | ₹4,275.00 |
| 500+ | ₹39.08 | ₹19,540.00 |
| 1,000+ | ₹37.14 | ₹37,140.00 |
1 × ₹71.68
₹71.68
excl. GST
₹84.58 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
STM1001RWX6F
₹71.68 for 1 + GST
Specifications
- Reset Timeout
- 30ms
- Operating Temperature
- -40℃~+85℃@(TA)
- output type
- Open-drain
- Reset Active Level
- Active Low
- standby current
- 5.5uA
- Voltage - Supply
- 1V~5.5V
- ChipType
- Voltage monitor
- Threshold Voltage
- 2.63V
- Number of Voltages Monitored
- 1
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.053 g
Overview
The STM1001 microprocessor reset circuit is a low-power supervisory device used to monitor power supplies. It performs a single function: asserting a reset signal whenever the V_CC supply voltage drops below a preset value and keeping it asserted until V_CC has risen above the preset threshold for a minimum period of time (t_rec).
Key features
- Precision monitoring of 3 V, 3.3 V, and 5 V supply voltages
- Open drain RST output
- 30 ms or 140 ms reset pulse width (min)
- Low supply current - 6 μA (typ)
- Guaranteed RST assertion down to V_CC = 1.0 V
- Operating temperature: -40 ℃ to 85 ℃ (industrial grade)
- Lead-free, small SOT23 package
Alternatives
Similar parts — check the datasheet before substituting.
