onsemiDatasheet (PDF)
SZ1SMA5921BT3G
1 Independent 6.46V~7.14V 6.8V SMA Single Zener Diodes RoHS
SMAROHS3 CompliantActive
- Manufacturer
- onsemi
- Manufacturer part #
- SZ1SMA5921BT3G
- Store part #
- C896066
- Package / case
- SMA
- Category
- Single Zener Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
167 in stock
#C896066
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹72.21 | ₹72.21 |
| 10+ | ₹70.48 | ₹704.80 |
| 30+ | ₹69.40 | ₹2,082.00 |
| 100+ | ₹68.32 | ₹6,832.00 |
1 × ₹72.21
₹72.21
excl. GST
₹85.21 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
SZ1SMA5921BT3G
₹72.21 for 1 + GST
Specifications
- Diode Configuration
- 1 Independent
- Tolerance
- ±5%
- Operating Junction Temperature Range
- -65℃~+150℃
- Pd - Power Dissipation
- 1.5W
- Reverse Leakage Current (Ir)
- 2.5uA@5.2V
- Impedance(Zzt)
- 2.5Ω
- Zener Voltage(Range)
- 6.46V~7.14V
- Zener Voltage(Nom)
- 6.8V
- Impedance(Zzk)
- 200Ω
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.115 g
Overview
Key features
- Standard Zener Breakdown Voltage Range - 3.3 V to 68 V
- ESD Rating of Class 3 (> 16 kV) per Human Body Model
- Flat Handling Surface for Accurate Placement
- Package Design for Top Slide or Bottom Circuit Board Mounting
- Low Profile Package
- Ideal Replacement for MELF Packages
- AEC - Q101 Qualified and PPAP Capable - SZ1SMA59xxBT3G
- SZ Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements
- These are Pb - Free Devices
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | 1SMA5921A#C5293613JSCJ · SMAG | JSCJ | SMAG | 4,655 | ₹11.25 · 4,655 in stock | View |
 | 1SMA5921BT3G#C38220onsemi · SMA | onsemi | SMA | 5,040 | ₹17.54 · 5,040 in stock | View |
 | SMA5921A#C5161052ZHIDE · SMA | ZHIDE | SMA | 175 | ₹12.79 · 175 in stock | View |
 | TP1SMA5921BT3G#C49274808TECH PUBLIC · SMA | TECH PUBLIC | SMA | 5,390 | ₹9.42 · 5,390 in stock | View |
 | SMAZ6V8-TP#C49274884TECH PUBLIC · SMA | TECH PUBLIC | SMA | 1,000 | ₹8.68 · 1,000 in stock | View |
